ABB CT-C Series DIN Rail Timer Relay, 2-Contact, 24 to 240 V ac 24/240 V ac, 0.05 s to 100 h, 1-Function, SPDT Switch

RS Stock No.:: 210-4292
Mfr. Part No.:: 1SVR508110R0100
Brand:: ABB

ABB CT-C Series DIN Rail Timer Relay, 2-Contact, 24 to 240 V ac 24/240 V ac, 0.05 s to 100 h, 1-Function, SPDT Switch

View all Timer Relays

Bulk discount available

Subtotal (1 unit)*

£55.26

(exc. VAT)

£66.31

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

12 unit(s) ready to ship
Plus 1 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 - 4	£55.26
5 - 9	£52.48
10 - 24	£49.73
25 - 49	£46.95
50 +	£44.22

*price indicative

RS Stock No.:: 210-4292
Mfr. Part No.:: 1SVR508110R0100
Brand:: ABB

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Product Type	Timer Relay
	Mount Type	DIN Rail
	Time Range	0.05 s to 100 h
	Number of Contacts	2
	Number of Timer Functions	1
	Contact Configuration	SPDT
	IP Rating	IP50, IP20
	Supply AC Voltage	24/240 V ac
	Minimum Operating Temperature	-20°C
	Contact Current	4A
	Supply DC Voltage	24 to 240 V ac
	Terminal Type	Screw
	Maximum Operating Temperature	60°C
	Length	63mm
	Width	17.5 mm
	Height	63mm
	Standards/Approvals	RoHS
	Series	CT-C

	Select all
	Brand ABB
	Product Type Timer Relay
	Mount Type DIN Rail
	Time Range 0.05 s to 100 h
	Number of Contacts 2
	Number of Timer Functions 1
	Contact Configuration SPDT
	IP Rating IP50, IP20
	Supply AC Voltage 24/240 V ac
	Minimum Operating Temperature -20°C
	Contact Current 4A
	Supply DC Voltage 24 to 240 V ac
	Terminal Type Screw
	Maximum Operating Temperature 60°C
	Length 63mm
	Width 17.5 mm
	Height 63mm
	Standards/Approvals RoHS
	Series CT-C

COO (Country of Origin):: BG

ABB Timer Relay, 2 Contacts, SPDT Configuration - CT-C Series - 1SVR508110R0100

Automate your control circuits to switch off after a set interval with this single-function electronic timer relay from ABB. Its delay function lets you programme the two SPDT contacts to deactivate the circuit after a pre-selected time and reactivate it when the clock starts running. As you can set the time period between 0.05 seconds and 100 hours, this unit is versatile and can meet the specific requirements of your control network. Installation by hand is easy as the relay's compatible with DIN rails and only needs a tightening torque of 0.5 to 0.8Nm during mounting.

Features & Benefits

• Compact measurements of 17.5 (W) x 80 (H) x 63mm (D) to fit into tight work areas

• Rated for supply voltages of 24 to 48V DC and 24 to 240V AC to suit both light-duty and powerful electrical systems

Applications

• Lighting automation

• HVAC systems

• Hydroelectric dams

Can I use this unit in challenging environments?

Yes you can, thanks to a wide operating temperature range between -20°C and +60°C. The IP20 rating of the relay's terminals indicates protection against dust and objects larger than 12mm, allowing for use in harsh work conditions.
