Vishay 33 Ω Wirewound Resistor 3 W 5 % AC03000003309JACCS
- RS Stock No.:
- 855-8737
- Mfr. Part No.:
- AC03000003309JACCS
- Brand:
- Vishay
Bulk discount available
Subtotal (1 pack of 5 units)*
£2.93
(exc. VAT)
£3.515
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 280 unit(s) ready to ship
- Plus 1,085 unit(s) shipping from 12 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 45 | £0.586 | £2.93 |
| 50 - 120 | £0.44 | £2.20 |
| 125 - 245 | £0.354 | £1.77 |
| 250 - 495 | £0.322 | £1.61 |
| 500 + | £0.296 | £1.48 |
*price indicative
- RS Stock No.:
- 855-8737
- Mfr. Part No.:
- AC03000003309JACCS
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Resistance | 33Ω | |
| Product Type | Resistor | |
| Power Rating | 3W | |
| Resistor Type | Cemented Leaded Wirewound | |
| Tolerance ± | 5% | |
| Packaging | Fan Folded | |
| Axial/Radial | Axial | |
| Technology | Wirewound | |
| Series | AC03 | |
| Automotive Standard | AEC-Q200 | |
| Lead Pitch Radial | 25mm | |
| Minimum Operating Temperature | -55°C | |
| Pin Count | 2 | |
| Maximum Operating Temperature | 250°C | |
| Height | 4.8mm | |
| Length | 13mm | |
| Standards/Approvals | UL | |
| Width | 4.8mm | |
| Diameter | 4.8mm | |
| Lead Diameter | 0.8mm | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Resistance 33Ω | ||
Product Type Resistor | ||
Power Rating 3W | ||
Resistor Type Cemented Leaded Wirewound | ||
Tolerance ± 5% | ||
Packaging Fan Folded | ||
Axial/Radial Axial | ||
Technology Wirewound | ||
Series AC03 | ||
Automotive Standard AEC-Q200 | ||
Lead Pitch Radial 25mm | ||
Minimum Operating Temperature -55°C | ||
Pin Count 2 | ||
Maximum Operating Temperature 250°C | ||
Height 4.8mm | ||
Length 13mm | ||
Standards/Approvals UL | ||
Width 4.8mm | ||
Diameter 4.8mm | ||
Lead Diameter 0.8mm | ||
AC03...CS Series 3W, Axial
AC03...CS is designed to be used as fusible safety resistor and also as an in-rush current limiting resistor for the normal operation
High grade ceramic core
Tinned Cu wire terminations
Special cement coating for immediate interruption without flame and explosion when mains voltage (230Vac) is applied
Non-flammable cement coating
Ceramic Wirewound, Axial - 1W to 17W
