TT ElectronicsBI 22Ω Thick Film Resistor 5W ±5% BPC5 220J
- RS Stock No.:
- 144-5984
- Mfr. Part No.:
- BPC5 220J
- Brand:
- TT Electronics/BI
Bulk discount available
Subtotal (1 tray of 50 units)*
£171.65
(exc. VAT)
£206.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 24 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
|---|---|---|
| 50 - 200 | £3.433 | £171.65 |
| 250 - 450 | £2.925 | £146.25 |
| 500 - 1200 | £2.692 | £134.60 |
| 1250 - 2450 | £2.62 | £131.00 |
| 2500 + | £2.589 | £129.45 |
*price indicative
- RS Stock No.:
- 144-5984
- Mfr. Part No.:
- BPC5 220J
- Brand:
- TT Electronics/BI
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TT Electronics/BI | |
| Resistance | 22Ω | |
| Power Rating | 5W | |
| Tolerance | ±5% | |
| Technology | Thick Film | |
| Series | BPC5 | |
| Maximum Operating Temperature | +155°C | |
| Temperature Coefficient | ±100ppm/°C | |
| Lead Pitch | 5.08mm | |
| Minimum Operating Temperature | -55°C | |
Select all | ||
|---|---|---|
Brand TT Electronics/BI | ||
Resistance 22Ω | ||
Power Rating 5W | ||
Tolerance ±5% | ||
Technology Thick Film | ||
Series BPC5 | ||
Maximum Operating Temperature +155°C | ||
Temperature Coefficient ±100ppm/°C | ||
Lead Pitch 5.08mm | ||
Minimum Operating Temperature -55°C | ||
- COO (Country of Origin):
- GB
Thick-film on ceramic offers a highly compact resistor technology for surge and overload applications. This Application Note illustrates some of the many applications, which range from PSU inrush suppression to high voltage laser supply current limiting, and the TT electronics products which meet their high surge requirements.
Non-Inductive planar package
High power density.
Thin package for high density PCB installation.
Power dissipated above the board
High power density.
Thin package for high density PCB installation.
Power dissipated above the board
