KEMET Tantalum Capacitor 68μF 6.3V dc MnO2 Solid ±20% Tolerance T491 Series

  • RS Stock No. 868-6198
  • Mfr. Part No. T491B686M006AT
  • Brand KEMET
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Kemet T491 Series

Kemet T491 Series tantalum surface mount capacitors, designed specifically for automated surface mount processes and equipment. The T491 combines Kemet’s proven solid tantalum technology, with the latest in materials, processes and automation, resulting in highly efficient and reliable capacitors. The T491 series terminations are 100% matte tin and provide excellent wetting characteristics and compatibility with surface mount solder systems.

Symmetrical, compliant terminations
Laser-marked case
Halogen free epoxy
Low profile case sizes
RoHS Compliant and lead-free terminations

Note

Black band on body indicates positive terminal.

Specifications
Attribute Value
Technology MnO2
Capacitance 68 µF
Voltage 6.3 V dc
Mounting Type Surface Mount
Package/Case 3528-21
Equivalent Series Resistance 900mΩ
Lead Pitch 1.9mm
Tolerance ±20%
Length 3.5mm
Depth 2.8mm
Height 1.9mm
Dimensions 3.5 x 2.8 x 1.9mm
Series T491
Electrolyte Type Solid
Leakage Current 4.3 μA
Minimum Operating Temperature -55°C
Dissipation Factor 8%
Dielectric Material Family Tantalum
Tolerance Plus +20%
Maximum Operating Temperature +125°C
Tolerance Minus -20%
Available to back order for despatch 07/08/2020
Price Each (In a Pack of 2000)
£ 0.227
(exc. VAT)
£ 0.272
(inc. VAT)
Units
Per unit
Per Pack*
2000 - 2000
£0.227
£454.00
4000 +
£0.206
£412.00
*price indicative
