C & K IP40 Blue Tactile Switch Button, SPST 50 mA 12 V dc, Surface
- RS Stock No.:
- 135-9484
- Mfr. Part No.:
- PTS645SM50SMTR 92 LFS
- Brand:
- C & K
Bulk discount available
Subtotal (1 pack of 20 units)*
£5.42
(exc. VAT)
£6.50
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 240 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 20 - 80 | £0.271 | £5.42 |
| 100 - 480 | £0.258 | £5.16 |
| 500 + | £0.243 | £4.86 |
*price indicative
- RS Stock No.:
- 135-9484
- Mfr. Part No.:
- PTS645SM50SMTR 92 LFS
- Brand:
- C & K
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | C & K | |
| Contact Configuration | SPST | |
| Product Type | Tactile Switch | |
| Terminal Type | Terminal | |
| Switch Operation | Momentary | |
| Actuator Colour | Blue | |
| Length | 6mm | |
| Illuminated | No | |
| Actuator Style | Button | |
| Contact DC Voltage | 12V dc | |
| Minimum Operating Temperature | -20°C | |
| Mount Type | Surface | |
| Actuator Orientation | Straight | |
| Maximum Operating Temperature | 60°C | |
| Switch Configuration | Off-Mom | |
| Standards/Approvals | RoHS | |
| Series | PTS | |
| IP Rating | IP40 | |
| Operating Force | 1.6N | |
| Height | 2mm | |
| Mechanical Life | 200000Cycles | |
| Select all | ||
|---|---|---|
Brand C & K | ||
Contact Configuration SPST | ||
Product Type Tactile Switch | ||
Terminal Type Terminal | ||
Switch Operation Momentary | ||
Actuator Colour Blue | ||
Length 6mm | ||
Illuminated No | ||
Actuator Style Button | ||
Contact DC Voltage 12V dc | ||
Minimum Operating Temperature -20°C | ||
Mount Type Surface | ||
Actuator Orientation Straight | ||
Maximum Operating Temperature 60°C | ||
Switch Configuration Off-Mom | ||
Standards/Approvals RoHS | ||
Series PTS | ||
IP Rating IP40 | ||
Operating Force 1.6N | ||
Height 2mm | ||
Mechanical Life 200000Cycles | ||
C&K PTS645 Series Tactile Switches
From C & K Switches, a range of straight and vertical termination SMT and THT tactile switches. The PTS645 series of switches are available with standard TOP actuation and various actuator lengths making them Ideal for applications where space is limited. Colour coded for easy identification of actuation force. The IP40 switches in the PTS645 family have a momentary function with SPST-NO contact arrangement.
Features and Benefits
• IP40
• 6 x 6 mm footprint
• Various actuator lengths
• Colour coded actuators for force identification
• Straight or vertical termination pins
Applications
• Industrial
• Consumer products
• Instrumentation
• Computers
Tactile
