BEL POWER SOLUTIONS INC Switching Regulator, Through Hole, 24V dc Output Voltage, 29 → 80V dc Input Voltage, 8A
- RS Stock No.:
- 837-1883
- Mfr. Part No.:
- PSC248-9IR
- Brand:
- BEL POWER SOLUTIONS INC
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 837-1883
- Mfr. Part No.:
- PSC248-9IR
- Brand:
- BEL POWER SOLUTIONS INC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | BEL POWER SOLUTIONS INC | |
| Output Voltage | 24V dc | |
| Output Current | 8A | |
| Input Voltage | 29 → 80V dc | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Efficiency | 95% | |
| Ripple And Noise | 155mV Pk-Pk | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +71°C | |
| Line Regulation | 220mV | |
| Load Regulation | 160mV | |
| MTBF | 68000 h, 143000 h, 660000 h, 2800000 h | |
| Weight | 440g | |
| Depth | 32.2mm | |
| Width | 88mm | |
| Length | 151mm | |
Select all | ||
|---|---|---|
Brand BEL POWER SOLUTIONS INC | ||
Output Voltage 24V dc | ||
Output Current 8A | ||
Input Voltage 29 → 80V dc | ||
Mounting Type Through Hole | ||
Number of Outputs 1 | ||
Efficiency 95% | ||
Ripple And Noise 155mV Pk-Pk | ||
Minimum Temperature -40°C | ||
Maximum Temperature +71°C | ||
Line Regulation 220mV | ||
Load Regulation 160mV | ||
MTBF 68000 h, 143000 h, 660000 h, 2800000 h | ||
Weight 440g | ||
Depth 32.2mm | ||
Width 88mm | ||
Length 151mm | ||
RoHS Status: Not Applicable
- COO (Country of Origin):
- SK
Power One - PSC Series
The PSC series switching regulators are power supplies for electronic systems where no input to output isolation is required. These switching regulators are reliable, have an excellent dynamic response and are highly efficient. Models with input voltages up to 144 V are designed for secondary switched and battery driven mobile applications. The PSC converters are wall or chassis mounted and are suitable for railway applications according to EN 50155 and EN 50121.
Input voltage up to 144 Vdc
Single output of 3.3 to 48 Vdc
High efficiency up to 97%
Extremely wide input voltage range
Low input to output differential voltage
Very good dynamic properties
Input under voltage lockout
Output voltage adjustment and inhibit function
Continuously no-load and short circuit proof
Single output of 3.3 to 48 Vdc
High efficiency up to 97%
Extremely wide input voltage range
Low input to output differential voltage
Very good dynamic properties
Input under voltage lockout
Output voltage adjustment and inhibit function
Continuously no-load and short circuit proof
Approvals
IEC, EN, UL,CSA
