EOS Switching Power Supply, LFMWLT150-1003-2, 24V dc, 4.17A, 150W, 1 Output, 120 → 390 V dc, 90 → 264 V
- RS Stock No.:
- 700-2407
- Mfr. Part No.:
- LFMWLT150-1003-2
- Brand:
- EOS
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£158.19
(exc. VAT)
£189.83
(inc. VAT)
- RS Stock No.:
- 700-2407
- Mfr. Part No.:
- LFMWLT150-1003-2
- Brand:
- EOS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EOS | |
| Output Voltage | 24V dc | |
| Output Current | 4.17A | |
| Power Rating | 150W | |
| Number of Outputs | 1 | |
| Input Voltage | 120 → 390 V dc, 90 → 264 V ac | |
| Mounting Type | Chassis Mount | |
| Package Type | Open Frame | |
| Length | 101.6mm | |
| Width | 50.8mm | |
| Medical Approved | Yes | |
| Depth | 33.64mm | |
| Weight | 150g | |
| Maximum Temperature | +70°C | |
| Minimum Temperature | -20°C | |
Select all | ||
|---|---|---|
Brand EOS | ||
Output Voltage 24V dc | ||
Output Current 4.17A | ||
Power Rating 150W | ||
Number of Outputs 1 | ||
Input Voltage 120 → 390 V dc, 90 → 264 V ac | ||
Mounting Type Chassis Mount | ||
Package Type Open Frame | ||
Length 101.6mm | ||
Width 50.8mm | ||
Medical Approved Yes | ||
Depth 33.64mm | ||
Weight 150g | ||
Maximum Temperature +70°C | ||
Minimum Temperature -20°C | ||
- COO (Country of Origin):
- IN
150 to 200W Medical Power Supply, MWLT Series
Class 1 and Class 2 product
Medical approval EN60601-1
O/P voltage adjustability
2x4 and 3x5 inch package options
High Efficiency
Harmonic correction to EN61000-3-2 class D
EMC meets EN55022 Class B, FCC Part 15 Class B
Over voltage, power limit and short circuit protection
Optional cover available, see stk nos. 666-7674
Medical approval EN60601-1
O/P voltage adjustability
2x4 and 3x5 inch package options
High Efficiency
Harmonic correction to EN61000-3-2 class D
EMC meets EN55022 Class B, FCC Part 15 Class B
Over voltage, power limit and short circuit protection
Optional cover available, see stk nos. 666-7674
Note
Manu. part nos. with '-2' suffix denote Class 2 products, those without are Class 1 products.
Standards
EN6061-1-2
Approvals
VDE, UL Recognised Component for Canada & US
