TRACOPOWER Switching Power Supply, TMPS 10-124 24V dc, 410mA, 10 W, Input 85V ac to 264V ac
- RS Stock No.:
- 181-0593
- Distrelec Article No.:
- 301-40-719
- Mfr. Part No.:
- TMPS 10-124
- Brand:
- TRACOPOWER
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£23.32
(exc. VAT)
£27.98
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 4 unit(s) shipping from 26 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £23.32 |
| 5 - 9 | £22.62 |
| 10 - 24 | £21.93 |
| 25 - 49 | £21.00 |
| 50 + | £20.06 |
*price indicative
- RS Stock No.:
- 181-0593
- Distrelec Article No.:
- 301-40-719
- Mfr. Part No.:
- TMPS 10-124
- Brand:
- TRACOPOWER
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TRACOPOWER | |
| Product Type | Switching Power Supply | |
| Maximum Output Voltage | 24V dc | |
| Number of Outputs | 1 | |
| Mount Type | PCB | |
| Power | 10W | |
| SMPS Output Current | 410mA | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Weight | 29g | |
| Depth | 25.4mm | |
| Width | 25.4mm | |
| Standards/Approvals | EN 55014-1, RoHS, IEC/EN/UL 62368-1, IEC/EN/UL 60950-1, IEC/EN 60335-1, FCC Part 15, EN 61000-4-8, EN 61000-4-6, EN 61000-4-5, EN 61000-4-4, EN 61000-4-3, EN 61000-4-11, EN 55032, EN 55024, EN 55014-2 | |
| Length | 38.5mm | |
| Maximum Input Voltage | 264V ac | |
| Efficiency | 86% | |
| Series | TMPS 10 | |
| Hazardous Area Certification | No | |
| Minimum Input Voltage | 85V ac | |
| Output Current | 410mA | |
| Select all | ||
|---|---|---|
Brand TRACOPOWER | ||
Product Type Switching Power Supply | ||
Maximum Output Voltage 24V dc | ||
Number of Outputs 1 | ||
Mount Type PCB | ||
Power 10W | ||
SMPS Output Current 410mA | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Weight 29g | ||
Depth 25.4mm | ||
Width 25.4mm | ||
Standards/Approvals EN 55014-1, RoHS, IEC/EN/UL 62368-1, IEC/EN/UL 60950-1, IEC/EN 60335-1, FCC Part 15, EN 61000-4-8, EN 61000-4-6, EN 61000-4-5, EN 61000-4-4, EN 61000-4-3, EN 61000-4-11, EN 55032, EN 55024, EN 55014-2 | ||
Length 38.5mm | ||
Maximum Input Voltage 264V ac | ||
Efficiency 86% | ||
Series TMPS 10 | ||
Hazardous Area Certification No | ||
Minimum Input Voltage 85V ac | ||
Output Current 410mA | ||
- COO (Country of Origin):
- TW
Traco Power TMPS 10 Series Switching Power Supply, 85 to 264V AC Input Voltage - TMPS 10-124
This efficient Traco Power 10W DC power supply with a 24V output is designed for industrial and household applications. It features high efficiency and reinforced I/O isolation, making it a reliable choice for various circuits.
Features & Benefits
• Ultra-compact 10W PCB power module
• Certified to meet safety standards for industrial and household appliances
• Reinforced I/O isolation up to 4000 VAC
• Operating temperature range of -25°C to +70°C
Applications
• Ideal for low power or segregated circuits
• Efficient standby mode powering
Can it be used for household appliances?
Yes, it is certified for household appliance applications.
Will it ensure safety in industrial settings?
It meets all the necessary safety standards for industrial use.
Is the power consumption efficient for low power circuits?
Yes, it complies with ErP directive for low power consumption.
