Eplax Switching Power Supply, 116-010070J, 12V dc, 10A, 120W, 1 Output, 115 V ac, 230 V ac Input Voltage
- RS Stock No.:
- 778-315
- Mfr. Part No.:
- 116-010070J
- Brand:
- Eplax
Available to back order for despatch 09/07/2024, delivery within 2 working days
Not available for guaranteed pre 9am/10am delivery
Added
Price Each
£411.39
(exc. VAT)
£493.67
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £411.39 |
| 5 - 9 | £399.05 |
| 10 - 24 | £386.71 |
| 25 - 49 | £374.37 |
| 50 + | £362.03 |
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 778-315
- Mfr. Part No.:
- 116-010070J
- Brand:
- Eplax
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
120 W Monovolt 19" Plug-in Power Supplies
120 W Primary Switch Plug-in Power Supplies with Assembly Cooling
Switchable input Voltage
For use in 19" rack mounts in accordance with DIN 41494
3 HE x 14 TE Euro cassette with 100 mm guide height
Safety in accordance with VDE 0805, EN60950
Sense mode and overvoltage protection (OVP)
Idling and short-circuit proof
Switch to serial or parallel
VERO standard plug fittings
No minimum load required
Switchable input Voltage
For use in 19" rack mounts in accordance with DIN 41494
3 HE x 14 TE Euro cassette with 100 mm guide height
Safety in accordance with VDE 0805, EN60950
Sense mode and overvoltage protection (OVP)
Idling and short-circuit proof
Switch to serial or parallel
VERO standard plug fittings
No minimum load required
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 12V dc |
| Output Current | 10A |
| Power Rating | 120W |
| Number of Outputs | 1 |
| Input Voltage | 115 V ac, 230 V ac |
| Mounting Type | 19" Rack Mount |
| Length | 190mm |
| Width | 110mm |
| Depth | 70.72mm |
| Series | PK |
| Maximum Temperature | +70°C |
| Minimum Temperature | 0°C |
| Weight | 1.4kg |
