MEAN WELL Switching Power Supply, QP-200D, 5 V dc, ±12 V dc, ±24 V dc, 3 A, 4 A, 15 A, 700mA, 203W, Quad Output, 127
- RS Stock No.:
- 414-064
- Mfr. Part No.:
- QP-200D
- Brand:
- MEAN WELL
11 In stock - FREE next working day delivery available
2 available from Europe for delivery within 1 working day(s).
Added
Price Each
£102.42
(exc. VAT)
£122.90
(inc. VAT)
Units | Per unit |
1 - 4 | £102.42 |
5 - 9 | £99.35 |
10 - 24 | £96.27 |
25 - 49 | £93.20 |
50 + | £90.13 |
- RS Stock No.:
- 414-064
- Mfr. Part No.:
- QP-200D
- Brand:
- MEAN WELL
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
QP-200 Series Quad Output Power Supply With PFC Function
High efficiency, long life and high reliability
Built-in fan
Easy installation - screw terminals
Adjustable output voltage (only on outputs 1 & 2, -5% to +10%)
Remote sense outputs 1 & 2
33.3% peak current capability
Power on LED indicator
Power factor correction to EN 61000-3-2
EMC meets EN 55022 Class B
100% full load burn-in test
Short circuit, over-load, over-voltage and over-temperature protection
Built-in fan
Easy installation - screw terminals
Adjustable output voltage (only on outputs 1 & 2, -5% to +10%)
Remote sense outputs 1 & 2
33.3% peak current capability
Power on LED indicator
Power factor correction to EN 61000-3-2
EMC meets EN 55022 Class B
100% full load burn-in test
Short circuit, over-load, over-voltage and over-temperature protection
Note
De-rate above 50°C operating temperature.
MTBF to MIL-HDBK-217F (25°C).
MTBF to MIL-HDBK-217F (25°C).
Standards
EN 60950-1, UL 60950-1
Approvals
TUV, CB, UL recognised component for Canada & US
Specifications
Attribute | Value |
---|---|
Output Voltage | 5 V dc, ±12 V dc, ±24 V dc |
Output Current | 3 A, 4 A, 15 A, 700mA |
Power Rating | 203W |
Number of Outputs | 4 |
Input Voltage | 127 → 370 V dc, 90 → 264 V ac |
Mounting Type | Chassis Mount |
Package Type | Enclosed |
Length | 215mm |
Width | 115mm |
Depth | 50mm |
Efficiency | 75% |
Minimum Temperature | -10°C |
Maximum Temperature | +60°C |
Weight | 1.2kg |
