RS PRO 51.1kΩ, 0805 (2012M) Thin Film Resistor 0.1% 0.4W

RS Stock No.:: 243-0682
Brand:: RS PRO

RS PRO 51.1kΩ, 0805 (2012M) Thin Film Resistor 0.1% 0.4W

Available to back order for despatch 12/03/2025

Price Each (On a Reel of 5000)

£0.182

(exc. VAT)

£0.218

(inc. VAT)

Units	Per unit	Per Reel*
5000 +	£0.182	£910.00

*price indicative

RS Stock No.:: 243-0682
Brand:: RS PRO

Technical Reference

RS PRO Datasheet

Legislation and Compliance

COO (Country of Origin):: TW

Product Details

RS PRO 0805 (2021M) Thin Film Current Sensing Chip Resistors

The RS PRO thin film surface mount (SMD) resistor controls the electrical current between a power source and an appliance, so the two can function together without burnout.
Featuring a thin film construction with a high purity alumina substrate for a higher level of precision than thick film resistors and superior levels of power dissipation.
The compact, lightweight design makes this SMD resistor ideal for use in small electronic devices, such as mobile phones.
Primarily used in the telecommunication and automotive industries the RS PRO 0805 resistors are also ideal for use in a wide range of other applications including:

Power Management Applications

Switching Power Supply

Over Current Protection in Audio Applications

Voltage Regulation Module (VRM)

DC-DC Converters, Battery Packs, Chargers and Adaptors

Automotive Engine Control

Disk Drivers

Portable Devices (PDA, Phones)

Features and Benefits

High purity alumina substrate for high power dissipation

Operating temperature range of -55 → +155°C

Temperature coefficient range of ±50 → ±100 ppm/°C

Thin film technology

Solder termination

Why RS PRO?

Looking to reduce costs but keep the same quality?
With a choice of over 65,000 products – all of which are rigorously tested against demanding industry standards before they are given the RS PRO seal of approval.
Trusted by engineers the world over, we want you to be confident that you’re receiving the exceptional quality, reliability and the best value for money.

Also available for purchase in a pack size of 5000. Please see RS 243-0682

Specifications

Attribute	Value
Resistance	51.1kΩ
Technology	Thin Film
Package/Case	0805 (2012M)
Tolerance	0.1%
Power Rating	0.4W
Temperature Coefficient	±50 → 100ppm/°C
Minimum Operating Temperature	-55°C
Maximum Operating Temperature	+155°C
