Arcol Ohmite 7.5Ω Thick Film SMD Resistor ±1% 45W
- RS Stock No.:
- 210-4708
- Mfr. Part No.:
- TKH45P7R50FE-TR
- Brand:
- Arcol Ohmite
Stock information currently inaccessible
- RS Stock No.:
- 210-4708
- Mfr. Part No.:
- TKH45P7R50FE-TR
- Brand:
- Arcol Ohmite
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Arcol Ohmite | |
| Resistance | 7.5Ω | |
| Technology | Thick Film | |
| Package/Case | TO-252 | |
| Tolerance | ±1% | |
| Power Rating | 45W | |
| Select all | ||
|---|---|---|
Brand Arcol Ohmite | ||
Resistance 7.5Ω | ||
Technology Thick Film | ||
Package/Case TO-252 | ||
Tolerance ±1% | ||
Power Rating 45W | ||
- COO (Country of Origin):
- JP
The Arcol Ohmite TKH Series , Small size, low profile, surge capable film resistor. It -55°C to +175°C temperature range provides for automotive applications. It has low thermal resistance under 3.0°C/W shows excellent cooling performance. It is easy to replace D-PAK power resistor.
Excellent rf characteristics for high speed pulse operation
Applications include snubber, gate control, bleeder, filter, rush current protection, PV, UPS and motor control inverters
Applications include snubber, gate control, bleeder, filter, rush current protection, PV, UPS and motor control inverters
