Isabellenhutte VMK 200mΩ, 1206 (3216M) Resistor ±1% 1.5W
- RS Stock No.:
- 192-9951
- Mfr. Part No.:
- VMK-R200-1.0-U
- Brand:
- Isabellenhutte
Subtotal (1 reel of 12500 units)*
£5,037.50
(exc. VAT)
£6,050.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
12500 + | £0.403 | £5,037.50 |
*price indicative
- RS Stock No.:
- 192-9951
- Mfr. Part No.:
- VMK-R200-1.0-U
- Brand:
- Isabellenhutte
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Isabellenhutte | |
Resistance | 200mΩ | |
Package/Case | 1206 (3216M) | |
Tolerance | ±1% | |
Power Rating | 1.5W | |
Temperature Coefficient | <20ppm/K | |
Automotive Standard | AEC-Q200 | |
Series | VMK | |
Minimum Operating Temperature | -65°C | |
Maximum Operating Temperature | +170°C | |
Select all | ||
---|---|---|
Brand Isabellenhutte | ||
Resistance 200mΩ | ||
Package/Case 1206 (3216M) | ||
Tolerance ±1% | ||
Power Rating 1.5W | ||
Temperature Coefficient <20ppm/K | ||
Automotive Standard AEC-Q200 | ||
Series VMK | ||
Minimum Operating Temperature -65°C | ||
Maximum Operating Temperature +170°C | ||
- COO (Country of Origin):
- DE
2 W power rating at 110 °C
Constant current up to 10 A (10 mohm)
Small size (1206)
High pulse power rating
Excellent long-term stability
Mounting: reflow- and Ir-soldering
Current sensor for power hybrid applications
Control systems for the automotive mart
Powe
Constant current up to 10 A (10 mohm)
Small size (1206)
High pulse power rating
Excellent long-term stability
Mounting: reflow- and Ir-soldering
Current sensor for power hybrid applications
Control systems for the automotive mart
Powe
