Subtotal (1 reel of 1000 units)*
£10.00
(exc. VAT)
£10.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 8,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
1000 + | £0.01 | £10.00 |
*price indicative
- RS Stock No.:
- 183-9841
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Resistance | 3.3MΩ | |
Technology | Thick Film | |
Package/Case | 1206 | |
Tolerance | 0.01 | |
Power Rating | 0.25W | |
Temperature Coefficient | ±200ppm/°C | |
Automotive Standard | No | |
Minimum Operating Temperature | -55°C | |
Maximum Operating Temperature | +155°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Resistance 3.3MΩ | ||
Technology Thick Film | ||
Package/Case 1206 | ||
Tolerance 0.01 | ||
Power Rating 0.25W | ||
Temperature Coefficient ±200ppm/°C | ||
Automotive Standard No | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature +155°C | ||
- COO (Country of Origin):
- TW
RS PRO Thick Film SMD Resistor
The RS PRO CR series thick film SMD chip resistor has a resistance of 3.3Mohm and a power rating value of 4W. This compact and lightweight resistor is compatible with all soldering processes. The resistor is used in watches, pocket calculators, and computers.
Features and Benefits
• Operating temperature ranges between -55°C and 155°C
• Temperature coefficient ranges between -250ppm/°C and 250ppm/°C
• Tolerance: ±1%
• Package/case: 1206 (3216M)
• Storage temperature: 15°C to 28°C
• Humidity < 80%RH
• Highly reliable multilayer electrode construction
• Long side terminations
• Temperature coefficient ranges between -250ppm/°C and 250ppm/°C
• Tolerance: ±1%
• Package/case: 1206 (3216M)
• Storage temperature: 15°C to 28°C
• Humidity < 80%RH
• Highly reliable multilayer electrode construction
• Long side terminations
Applications
• Telecommunication equipments
• Radio and tape recorders
• TV tuners
• Digital cameras
• Medical and military equipment
• Radio and tape recorders
• TV tuners
• Digital cameras
• Medical and military equipment
Certifications
• ANSI/ESD S20.20: 2014
• BS EN 61340-5-1: 2007
• BS EN 61340-5-1: 2007
