Susumu Co KRL 1mΩ, 0612 (1632M) Metal Foil SMD Resistor ±5% 1.5W

View all Surface Mount Resistors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
134-6368
Mfr. Part No.:
KRL3216E-C-R001-J
Brand:
Susumu Co
Find similar products by selecting one or more attributes.
Select all

Brand

Susumu Co

Resistance

1mΩ

Technology

Metal Foil

Package/Case

0612 (1632M)

Tolerance

±5%

Power Rating

1.5W

Temperature Coefficient

±150ppm/°C

Series

KRL

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

+175°C

COO (Country of Origin):
JP

Susumu KLR 1206 Current Sensing Resistors


Susumu KLR Series high current sensing long side terminal chip resistor features a high current handling capability and wide range of power ratings.Two types available: high temperature (operating temperature up to 175℃), low emf type (operating temperature up to 155℃).Face down construction. Choice between bottom only or wraparound terminal.

Features


Separated voltage terminal for precise measurement of voltage
TCR stable at very low resistance: 4 mΩ：±50ppm/℃
Power ratings: 1 W ∼ 5 W

Applications


Smartphones
Automotive electronics
Power source devices
AC-DC convertors
DC-DC convertors
Motors
Inverters
Office automation equipment

Approvals

AEC-Q200 Compliant
Prepare the line-up for current sensing resistors which cover a wide range of high-power and miniaturization needs. From the various type of shunt resistors such as short side, long side and four-terminal, customers can select the most appropriate resistance value for sensing current precisely.

Metal foil low resistance chip resistors (4 terminal type） KRL series

Separated voltage terminal for precise measurement of voltage
TCR stable at very low resistance: 4mΩ：±50ppm/℃
Power ratings: 1W ∼ 5W.
