Bourns CR 560 Ω, 0603 Thick Film Resistor 1 % Surface Mount 100 mW - CR0603-FX-5600ELF
- RS Stock No.:
- 630-361
- Mfr. Part No.:
- CR0603-FX-5600ELF
- Brand:
- Bourns
Bulk discount available
Subtotal (1 tape of 20 units)*
£0.18
(exc. VAT)
£0.22
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 24,160 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 20 - 480 | £0.009 | £0.18 |
| 500 - 1980 | £0.008 | £0.16 |
| 2000 - 9980 | £0.006 | £0.12 |
| 10000 + | £0.005 | £0.10 |
*price indicative
- RS Stock No.:
- 630-361
- Mfr. Part No.:
- CR0603-FX-5600ELF
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Resistor | |
| Resistance | 560Ω | |
| Technology | Thick Film | |
| Resistor Type | Thick Film | |
| Package/Case | 0603 | |
| Tolerance | 1 % | |
| Packaging | Paper Tape | |
| Power Rating | 100mW | |
| Voltage | 75V | |
| Mount Type | Surface Mount | |
| Temperature Coefficient | ±100 ppm/°C | |
| Series | CR | |
| Pin Count | 2 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 155°C | |
| Length | 1.6mm | |
| Termination Style | Lead Free Terminations (Tinned) | |
| Width | 0.8mm | |
| Standards/Approvals | RoHS | |
| Height | 0.45mm | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Resistor | ||
Resistance 560Ω | ||
Technology Thick Film | ||
Resistor Type Thick Film | ||
Package/Case 0603 | ||
Tolerance 1 % | ||
Packaging Paper Tape | ||
Power Rating 100mW | ||
Voltage 75V | ||
Mount Type Surface Mount | ||
Temperature Coefficient ±100 ppm/°C | ||
Series CR | ||
Pin Count 2 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 155°C | ||
Length 1.6mm | ||
Termination Style Lead Free Terminations (Tinned) | ||
Width 0.8mm | ||
Standards/Approvals RoHS | ||
Height 0.45mm | ||
- COO (Country of Origin):
- TW
The Bourns Thick Film Chip Resistors with 1% and 5% tolerance options ensure precise performance. A three-layer termination with a nickel barrier prevents leaching and improves solderability. Available in tape and reel packaging for efficient automated assembly. Ideal for a wide range of electronic applications.
RoHS compliant
Tight tolerance of bottom electrode width
