Bourns CHV 1 mΩ, 2512 Thick Film Resistor 1 % Surface Mount 1 W - CHV2512-FX-1005EST
- RS Stock No.:
- 630-223
- Mfr. Part No.:
- CHV2512-FX-1005EST
- Brand:
- Bourns
Bulk discount available
Subtotal (1 tape of 20 units)*
£3.98
(exc. VAT)
£4.78
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 8,000 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 20 - 180 | £0.199 | £3.98 |
| 200 - 980 | £0.162 | £3.24 |
| 1000 - 1980 | £0.124 | £2.48 |
| 2000 + | £0.11 | £2.20 |
*price indicative
- RS Stock No.:
- 630-223
- Mfr. Part No.:
- CHV2512-FX-1005EST
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Resistance | 1mΩ | |
| Product Type | Resistor | |
| Technology | Thick Film | |
| Resistor Type | Thick Film | |
| Package/Case | 2512 | |
| Packaging | Plastic Reel | |
| Tolerance | 1 % | |
| Voltage | 3000V | |
| Power Rating | 1W | |
| Mount Type | Surface Mount | |
| Temperature Coefficient | ±100 ppm/°C | |
| Series | CHV | |
| Minimum Operating Temperature | -55°C | |
| Pin Count | 2 | |
| Maximum Operating Temperature | 155°C | |
| Length | 6.4mm | |
| Standards/Approvals | RoHS | |
| Width | 3.2mm | |
| Height | 0.6mm | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Resistance 1mΩ | ||
Product Type Resistor | ||
Technology Thick Film | ||
Resistor Type Thick Film | ||
Package/Case 2512 | ||
Packaging Plastic Reel | ||
Tolerance 1 % | ||
Voltage 3000V | ||
Power Rating 1W | ||
Mount Type Surface Mount | ||
Temperature Coefficient ±100 ppm/°C | ||
Series CHV | ||
Minimum Operating Temperature -55°C | ||
Pin Count 2 | ||
Maximum Operating Temperature 155°C | ||
Length 6.4mm | ||
Standards/Approvals RoHS | ||
Width 3.2mm | ||
Height 0.6mm | ||
- COO (Country of Origin):
- TW
The Bourns Chip Resistor features thick film construction, making it suitable for High Voltage applications. It offers a wide resistance range from 100 kΩ to 10 MΩ and operates within a temperature range of -55°C to +155°C. Applications include High Voltage Applications and Consumer Electronics.
RoHS compliant
UL/IEC 60950 and 60065 compatible
UL 1676 recognized
