Bourns CRS 1 Ω, 1206 Thick Film Resistor 1 % Surface Mount 500 mW - CRS1206AFX-1R00ELF
- RS Stock No.:
- 630-177
- Mfr. Part No.:
- CRS1206AFX-1R00ELF
- Brand:
- Bourns
Bulk discount available
Subtotal (1 tape of 20 units)*
£2.00
(exc. VAT)
£2.40
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 9,920 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 20 - 180 | £0.10 | £2.00 |
| 200 - 480 | £0.065 | £1.30 |
| 500 - 1980 | £0.05 | £1.00 |
| 2000 - 9980 | £0.049 | £0.98 |
| 10000 + | £0.048 | £0.96 |
*price indicative
- RS Stock No.:
- 630-177
- Mfr. Part No.:
- CRS1206AFX-1R00ELF
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Resistance | 1Ω | |
| Product Type | Resistor | |
| Resistor Type | High Power | |
| Technology | Thick Film | |
| Package/Case | 1206 | |
| Packaging | Reel | |
| Tolerance | 1 % | |
| Voltage | 150V | |
| Power Rating | 500mW | |
| Temperature Coefficient | ±100 ppm/°C | |
| Mount Type | Surface Mount | |
| Series | CRS | |
| Pin Count | 2 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 155°C | |
| Width | 1.6mm | |
| Termination Style | Lead Free Terminations (Tinned) | |
| Standards/Approvals | RoHS | |
| Length | 3.1mm | |
| Height | 0.55mm | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Resistance 1Ω | ||
Product Type Resistor | ||
Resistor Type High Power | ||
Technology Thick Film | ||
Package/Case 1206 | ||
Packaging Reel | ||
Tolerance 1 % | ||
Voltage 150V | ||
Power Rating 500mW | ||
Temperature Coefficient ±100 ppm/°C | ||
Mount Type Surface Mount | ||
Series CRS | ||
Pin Count 2 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 155°C | ||
Width 1.6mm | ||
Termination Style Lead Free Terminations (Tinned) | ||
Standards/Approvals RoHS | ||
Length 3.1mm | ||
Height 0.55mm | ||
- COO (Country of Origin):
- TW
The Bourns High Power Anti-Surge Chip Resistor is designed to withstand surge conditions and operates within a temperature range of -55°C to +155°C. It is Ideal for use in Pulse Power Applications, High Voltage Applications, Consumer Electronics, Telecommunications, and Power Supplies.
Wide resistance range
RoHS compliant
