Wurth, WE-PD, 7332 Shielded Wire-wound SMD Inductor 220 μH ±20% Wire-Wound 430mA Idc
- RS Stock No.:
- 798-1644
- Distrelec Article No.:
- 301-89-513
- Mfr. Part No.:
- 7447789222
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 unit)*
£1.11
(exc. VAT)
£1.33
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 778 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 9 | £1.11 |
10 - 49 | £0.99 |
50 - 99 | £0.96 |
100 - 999 | £0.94 |
1000 + | £0.91 |
*price indicative
- RS Stock No.:
- 798-1644
- Distrelec Article No.:
- 301-89-513
- Mfr. Part No.:
- 7447789222
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Inductance | 220 μH | |
Maximum DC Current | 430mA | |
Package/Case | 7332 | |
Length | 7.3mm | |
Depth | 7.3mm | |
Height | 3.2mm | |
Dimensions | 7.3 x 7.3 x 3.2mm | |
Shielded | Yes | |
Tolerance | ±20% | |
Maximum DC Resistance | 1.65Ω | |
Series | WE-PD | |
Maximum Self Resonant Frequency | 5.6MHz | |
Inductor Construction | Wire-Wound | |
Maximum Operating Temperature | +125°C | |
Minimum Operating Temperature | -40°C | |
Moulded | Yes | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Inductance 220 μH | ||
Maximum DC Current 430mA | ||
Package/Case 7332 | ||
Length 7.3mm | ||
Depth 7.3mm | ||
Height 3.2mm | ||
Dimensions 7.3 x 7.3 x 3.2mm | ||
Shielded Yes | ||
Tolerance ±20% | ||
Maximum DC Resistance 1.65Ω | ||
Series WE-PD | ||
Maximum Self Resonant Frequency 5.6MHz | ||
Inductor Construction Wire-Wound | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -40°C | ||
Moulded Yes | ||
- COO (Country of Origin):
- CN
WE-PD Series Magnetically Shielded Wire Wound Chokes
Wurth WE-PD wirewound surface mount inductor is magnetically shielded resulting in a low leakage field. These power inductors have high storage capacity and high current loading. Recommended solder profile: Reflow. Operating temperature -40 to +125°C.
Applications
Switching regulators with low operating voltages
Integrated DC-DC converters
Switching regulators with high efficiency (>86%)
Graphic cards
Integrated DC-DC converters
Switching regulators with high efficiency (>86%)
Graphic cards
Note
Plastic base variant applications are particularly suited to high vibration or shock applications due to its one piece construction.
