Wurth Elektronik, WE-LQS SMT, 5040 Shielded Power Inductor with a Manganese Zinc Core, 2.2 mH Semi Shielded ±10 % 180 mA
- RS Stock No.:
- 258-5606
- Mfr. Part No.:
- 74404054222
- Brand:
- Wurth Elektronik
Bulk discount available
View bulk pricing optionsSubtotal (1 tape of 5 units)*
£4.34
(exc. VAT)
£5.21
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 06 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 20 | £0.868 | £4.34 |
| 25 - 45 | £0.82 | £4.10 |
| 50 - 95 | £0.736 | £3.68 |
| 100 - 245 | £0.66 | £3.30 |
| 250 + | £0.578 | £2.89 |
*price indicative
- RS Stock No.:
- 258-5606
- Mfr. Part No.:
- 74404054222
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Power Inductor | |
| Inductance | 2.2mH | |
| Maximum DC Current | 180mA | |
| Package/Case | 5040 | |
| Length | 5mm | |
| Packaging | Tape & Reel | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Maximum DC Resistance | 12900mΩ | |
| Minimum Operating Temperature | -40°C | |
| Series | WE-LQS SMT | |
| Inductance Tolerance | ±10 % | |
| Maximum Operating Temperature | 125°C | |
| Depth | 4mm | |
| Core Material | Manganese Zinc | |
| Height | 4mm | |
| Standards/Approvals | RoHS, AEC-Q200, DIN EN 61760-2, DIN ISO 2768, IEC 61249-2-21, JEDEC JS709B, REACH | |
| Maximum Self Resonant Frequency | 1.3MHz | |
| Inductor Construction | Semi Shielded | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Power Inductor | ||
Inductance 2.2mH | ||
Maximum DC Current 180mA | ||
Package/Case 5040 | ||
Length 5mm | ||
Packaging Tape & Reel | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Maximum DC Resistance 12900mΩ | ||
Minimum Operating Temperature -40°C | ||
Series WE-LQS SMT | ||
Inductance Tolerance ±10 % | ||
Maximum Operating Temperature 125°C | ||
Depth 4mm | ||
Core Material Manganese Zinc | ||
Height 4mm | ||
Standards/Approvals RoHS, AEC-Q200, DIN EN 61760-2, DIN ISO 2768, IEC 61249-2-21, JEDEC JS709B, REACH | ||
Maximum Self Resonant Frequency 1.3MHz | ||
Inductor Construction Semi Shielded | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik SMT power inductor with magnetically shielded by use of a magnetic resin, for use as switching controllers which require high efficiency. Big sizes can be used in shock resisting circuits.
Robust construction
Compact design Power Inductor
1.7 times more current than compared to an unshielded version
