Bourns, 7028 Power Inductor 8.2 μH 4.5A Idc
- RS Stock No.:
- 247-6147P
- Mfr. Part No.:
- SRP7028AA-8R2M
- Brand:
- Bourns
Bulk discount available
Subtotal 10 units (supplied on a continuous strip)*
£4.30
(exc. VAT)
£5.20
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 743 unit(s) shipping from 13 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 10 - 49 | £0.43 |
| 50 - 99 | £0.42 |
| 100 - 499 | £0.41 |
| 500 + | £0.40 |
*price indicative
- RS Stock No.:
- 247-6147P
- Mfr. Part No.:
- SRP7028AA-8R2M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 8.2 μH | |
| Maximum DC Current | 4.5A | |
| Package/Case | 7028 | |
| Length | 7.1 x 6.6 x 2.8mm | |
| Automotive Standard | AEC-Q200 | |
| Depth | 6.6mm | |
Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 8.2 μH | ||
Maximum DC Current 4.5A | ||
Package/Case 7028 | ||
Length 7.1 x 6.6 x 2.8mm | ||
Automotive Standard AEC-Q200 | ||
Depth 6.6mm | ||
- COO (Country of Origin):
- CN
The Bourns SRP7028AA series power Inductor are manufactured with a metal alloy powder core featuring high saturation current and shielded construction for low magnetic radiation. It is AEC-Q200 qualified and 8.2 μH inductance with 4.5 A rated current.
Low buzz noise
Operating temperature is -55 °C to 155 °C
Halogen free
RoHS compliant
Operating temperature is -55 °C to 155 °C
Halogen free
RoHS compliant
