Vishay, IHLE2525, 2225 (5664M) Shielded Wire-wound SMD Inductor 2.2 μH 20% Shielded 8.1A Idc
- RS Stock No.:
- 228-8651
- Mfr. Part No.:
- IHLE2525CDER2R2M5A
- Brand:
- Vishay
290 In stock - FREE next working day delivery available
Price Each (On a Reel of 1000)
£0.63
(exc. VAT)
£0.76
(inc. VAT)
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £0.63 | £630.00 |
*price indicative
- RS Stock No.:
- 228-8651
- Mfr. Part No.:
- IHLE2525CDER2R2M5A
- Brand:
- Vishay
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
The Vishay IHLE5050 series high current inductors with E-field shield. It has a 2.2uH inductance and package type is 2525.High current inductors with E-field shield are passive circuit components, meaning they require an external power source.
High temperature, up to 155 °C
Integrated E-Shield for maximum EMI reduction (1)
Excellent DC/DC energy storage up to 1 MHz to 2 MHz Filter inductor applications up the SRF
Integrated E-Shield for maximum EMI reduction (1)
Excellent DC/DC energy storage up to 1 MHz to 2 MHz Filter inductor applications up the SRF
Specifications
Attribute | Value |
|---|---|
| Inductance | 2.2 μH |
| Maximum DC Current | 8.1A |
| Package/Case | 2225 (5664M) |
| Length | 7.21mm |
| Automotive Standard | AEC-Q200 |
| Depth | 3.23mm |
| Shielded | Yes |
| Tolerance | 20% |
| Series | IHLE2525 |
| Inductor Construction | Shielded |
