Vishay, IHLP, 5050 Shielded Surface Mount Inductor with a Metal Composite Core, 4.7 μH ±20 % 12 A Idc
- RS Stock No.:
- 223-7297
- Mfr. Part No.:
- IHLP5050FDER4R7M01
- Brand:
- Vishay
Bulk discount available
Subtotal (1 reel of 250 units)*
£252.25
(exc. VAT)
£302.75
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Reel* |
|---|---|---|
| 250 - 250 | £1.009 | £252.25 |
| 500 + | £0.908 | £227.00 |
*price indicative
- RS Stock No.:
- 223-7297
- Mfr. Part No.:
- IHLP5050FDER4R7M01
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Surface Mount Inductor | |
| Inductance | 4.7μH | |
| Maximum DC Current | 12A | |
| Package/Case | 5050 | |
| Length | 12.9mm | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 8.7mΩ | |
| Inductance Tolerance | ±20 % | |
| Series | IHLP | |
| Maximum Operating Temperature | 125°C | |
| Core Material | Metal Composite | |
| Height | 6.4mm | |
| Depth | 6.5mm | |
| Standards/Approvals | JEDEC, RoHS | |
| Termination Style | Surface Mount | |
| Maximum Self Resonant Frequency | 32MHz | |
| Moulded | Yes | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Surface Mount Inductor | ||
Inductance 4.7μH | ||
Maximum DC Current 12A | ||
Package/Case 5050 | ||
Length 12.9mm | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 8.7mΩ | ||
Inductance Tolerance ±20 % | ||
Series IHLP | ||
Maximum Operating Temperature 125°C | ||
Core Material Metal Composite | ||
Height 6.4mm | ||
Depth 6.5mm | ||
Standards/Approvals JEDEC, RoHS | ||
Termination Style Surface Mount | ||
Maximum Self Resonant Frequency 32MHz | ||
Moulded Yes | ||
Inductor Construction Shielded | ||
The Vishay IHLP commercial inductors handles high transient current spikes without saturation. It has ultra low buzz noise, due to composite construction. It can be used in high current POL converters. It has 4.7 μH inductance.
RoHS compliant
Halogen free
