EPCOS, B82422A*100, 1210 (3225M) Wire-wound SMD Inductor with a Ferrite Core, 3.3 μH ±10% Wire-Wound 200mA Idc Q:27
- RS Stock No.:
- 191-0324P
- Mfr. Part No.:
- B82422A1332K100
- Brand:
- EPCOS
985 In stock - FREE next working day delivery available
Added
Price Each (Supplied on a Reel) Quantities below 150 on continuous strip
£0.368
(exc. VAT)
£0.442
(inc. VAT)
| Units | Per unit |
| 5 + | £0.368 |
- RS Stock No.:
- 191-0324P
- Mfr. Part No.:
- B82422A1332K100
- Brand:
- EPCOS
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
Epcos 1210 B82422A SIMID Series Wire Wound Inductors
High Q factor
High resonance frequency
Suitable for reflow (IR and vapour phase) and wave soldering
High resonance frequency
Suitable for reflow (IR and vapour phase) and wave soldering
Specifications
Attribute | Value |
|---|---|
| Inductance | 3.3 μH |
| Maximum DC Current | 200mA |
| Package/Case | 1210 (3225M) |
| Length | 3.2mm |
| Depth | 2.5mm |
| Height | 2mm |
| Dimensions | 3.2 x 2.5 x 2mm |
| Tolerance | ±10% |
| Maximum DC Resistance | 1.2Ω |
| Series | B82422A*100 |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 110MHz |
| Inductor Construction | Wire-Wound |
| Minimum Operating Temperature | -55°C |
| Minimum Quality Factor | 27 |
| Moulded | Yes |
| Maximum Operating Temperature | +125°C |
- RS Stock No.:
- 191-0324P
- Mfr. Part No.:
- B82422A1332K100
- Brand:
- EPCOS
