TDK, NLFV-EF, 1210 (3225M) Shielded Wire-wound SMD Inductor with a Ferrite Core, 33 μH ±10% Wire-Wound 95mA Idc
- RS Stock No.:
- 185-7697
- Mfr. Part No.:
- NLFV32T-330K-EF
- Brand:
- TDK
980 In stock - FREE next working day delivery available
Price Each (On a Reel of 2000)
£0.138
(exc. VAT)
£0.166
(inc. VAT)
Units | Per unit | Per Reel* |
|---|---|---|
| 2000 + | £0.138 | £276.00 |
*price indicative
- RS Stock No.:
- 185-7697
- Mfr. Part No.:
- NLFV32T-330K-EF
- Brand:
- TDK
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
Resin mold type wound inductor for decoupling circuits
Magnetic shield type containing ferrite powder in the exterior mold resin
Operating temperature range: –40 to +105°C (including self-temperature rise)
Application
Smart meters, AV equipment, xDSL, electronic devices for communications infrastructure such as mobile base stations, industrial equipment, other
Magnetic shield type containing ferrite powder in the exterior mold resin
Operating temperature range: –40 to +105°C (including self-temperature rise)
Application
Smart meters, AV equipment, xDSL, electronic devices for communications infrastructure such as mobile base stations, industrial equipment, other
Specifications
Attribute | Value |
|---|---|
| Inductance | 33 μH |
| Maximum DC Current | 95mA |
| Package/Case | 1210 (3225M) |
| Length | 3.2mm |
| Depth | 2.5mm |
| Height | 2.2mm |
| Dimensions | 3.2 x 2.5 x 2.2mm |
| Shielded | Yes |
| Tolerance | ±10% |
| Maximum DC Resistance | 780mΩ |
| Series | NLFV-EF |
| Core Material | Ferrite |
| Maximum Self Resonant Frequency | 2.52MHz |
| Moulded | Yes |
| Minimum Operating Temperature | -40°C |
| Inductor Construction | Wire-Wound |
| Maximum Operating Temperature | +105°C |
