Wurth, WE-PD, 7345 Shielded Wire-wound SMD Inductor with a MnZn Core, 680 μH ±20% Shielded 360mA Idc
- RS Stock No.:
- 185-7054
- Mfr. Part No.:
- 7447773681
- Brand:
- Wurth Elektronik
999999999 In stock - FREE next working day delivery available
Price Each (On a Reel of 1000)
£1.01
(exc. VAT)
£1.21
(inc. VAT)
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £1.01 | £1,010.00 |
*price indicative
- RS Stock No.:
- 185-7054
- Mfr. Part No.:
- 7447773681
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Ultra low RDC and RAC
Highest possible saturation current based on Ferrite
Suitable for switching frequency up to 10MHz
Temperature dependent parameter available on Redexpert
Operating Temperature from -40°C to +125°C / +150°C
Types- WE-PD: Since always with low loss material, tight tolerances and high saturation behavior compared to other manufacturers in the market, WE-PD Robust: Plastic base improves the mechanical stability and efficiency, WE-PD Performance: MnZn core improves Saturation and RDC for highest efficiency
Applications
Switch Mode Power supplies from 0,1W up to 300W
Integrated DC DC Converter
Ideal for Switch Mode Power supplies with extreme high efficiency (>95%)
Highest possible saturation current based on Ferrite
Suitable for switching frequency up to 10MHz
Temperature dependent parameter available on Redexpert
Operating Temperature from -40°C to +125°C / +150°C
Types- WE-PD: Since always with low loss material, tight tolerances and high saturation behavior compared to other manufacturers in the market, WE-PD Robust: Plastic base improves the mechanical stability and efficiency, WE-PD Performance: MnZn core improves Saturation and RDC for highest efficiency
Applications
Switch Mode Power supplies from 0,1W up to 300W
Integrated DC DC Converter
Ideal for Switch Mode Power supplies with extreme high efficiency (>95%)
Specifications
Attribute | Value |
|---|---|
| Inductance | 680 μH |
| Maximum DC Current | 360mA |
| Package/Case | 7345 |
| Length | 7.3mm |
| Depth | 7.4mm |
| Automotive Standard | AEC-Q200 |
| Height | 4.5mm |
| Dimensions | 7.3 x 7.4 x 4.5mm |
| Shielded | Yes |
| Tolerance | ±20% |
| Maximum DC Resistance | 2.3Ω |
| Series | WE-PD |
| Core Material | MnZn |
| Maximum Self Resonant Frequency | 2.3MHz |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +150°C |
| Inductor Construction | Shielded |
