Vishay, IHLP, 5050 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 560 nH ±20% Shielded 37A Idc
- RS Stock No.:
- 172-9075
- Mfr. Part No.:
- IHLP5050FDERR56M01
- Brand:
- Vishay
Available to back order for despatch 08/08/2024
Added
Price Each (On a Reel of 250)
£1.176
(exc. VAT)
£1.411
(inc. VAT)
| Units | Per unit | Per Reel* |
| 250 - 250 | £1.176 | £294.00 |
| 500 + | £1.058 | £264.50 |
| *price indicative | ||
- RS Stock No.:
- 172-9075
- Mfr. Part No.:
- IHLP5050FDERR56M01
- Brand:
- Vishay
Legislation and Compliance
Product Details
IHLP5050FD-01 Series Magnetically Shielded Wire Wound Chokes
Vishay IHLP-5050FD-01 series high current low profile shielded inductors. The IHLP-5050FD-01 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction.
Frequency range up to 5.0 MHz
Lowest DC Resistance / μH in this package size
Lowest DC Resistance / μH in this package size
Applications include: PDA/notebook/desktop/server devices; High current POL converters; Low profile, high current power supplies; Battery powered devices; DC/DC converters in distributed power systems; DC/DC converter for Field Programmable Gate Array (FPGA)
Vishay Non Standard SMT Inductors (Chokes)
Specifications
Attribute | Value |
|---|---|
| Inductance | 560 nH |
| Maximum DC Current | 37A |
| Package/Case | 5050 |
| Length | 13.2mm |
| Depth | 12.9mm |
| Height | 6.5mm |
| Dimensions | 13.2 x 12.9 x 6.5mm |
| Shielded | Yes |
| Tolerance | ±20% |
| Maximum DC Resistance | 1.4mΩ |
| Series | IHLP |
| Core Material | Metal Composite |
| Maximum Self Resonant Frequency | 5MHz |
| Inductor Construction | Shielded |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55°C |
