Bourns, SRP7028A, 7028 Shielded Wire-wound SMD Inductor with a Carbonyl Powder Core, 560 nH ±20% Wire-Wound 16.5A Idc
- RS Stock No.:
- 172-8586
- Mfr. Part No.:
- SRP7028A-R56M
- Brand:
- Bourns
Bulk discount available
Subtotal (1 reel of 1000 units)*
£470.00
(exc. VAT)
£560.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 - 1000 | £0.47 | £470.00 |
| 2000 - 2000 | £0.457 | £457.00 |
| 3000 + | £0.446 | £446.00 |
*price indicative
- RS Stock No.:
- 172-8586
- Mfr. Part No.:
- SRP7028A-R56M
- Brand:
- Bourns
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Inductance | 560 nH | |
| Maximum DC Current | 16.5A | |
| Package/Case | 7028 | |
| Length | 7.3mm | |
| Automotive Standard | AEC-Q200 | |
| Depth | 6.6mm | |
| Height | 2.8mm | |
| Dimensions | 7.3 x 6.6 x 2.8mm | |
| Shielded | Yes | |
| Tolerance | ±20% | |
| Maximum DC Resistance | 5mΩ | |
| Series | SRP7028A | |
| Core Material | Carbonyl Powder | |
| Maximum Self Resonant Frequency | 70MHz | |
| Minimum Quality Factor | 15 | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +150°C | |
| Moulded | Yes | |
| Inductor Construction | Wire-Wound | |
Select all | ||
|---|---|---|
Brand Bourns | ||
Inductance 560 nH | ||
Maximum DC Current 16.5A | ||
Package/Case 7028 | ||
Length 7.3mm | ||
Automotive Standard AEC-Q200 | ||
Depth 6.6mm | ||
Height 2.8mm | ||
Dimensions 7.3 x 6.6 x 2.8mm | ||
Shielded Yes | ||
Tolerance ±20% | ||
Maximum DC Resistance 5mΩ | ||
Series SRP7028A | ||
Core Material Carbonyl Powder | ||
Maximum Self Resonant Frequency 70MHz | ||
Minimum Quality Factor 15 | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +150°C | ||
Moulded Yes | ||
Inductor Construction Wire-Wound | ||
