TDK, SPM, 6550 Shielded Wire-wound SMD Inductor with a Metallic Magnetic Core, 4.7 μH ±20% Wire-Wound 7A Idc
- RS Stock No.:
- 134-6242
- Mfr. Part No.:
- SPM6550T-4R7M
- Brand:
- TDK
Bulk discount available
Subtotal (1 pack of 5 units)*
£4.47
(exc. VAT)
£5.365
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
5 - 45 | £0.894 | £4.47 |
50 - 95 | £0.67 | £3.35 |
100 - 245 | £0.582 | £2.91 |
250 - 495 | £0.536 | £2.68 |
500 + | £0.492 | £2.46 |
*price indicative
- RS Stock No.:
- 134-6242
- Mfr. Part No.:
- SPM6550T-4R7M
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TDK | |
Inductance | 4.7 μH | |
Maximum DC Current | 7A | |
Package/Case | 6550 | |
Length | 7.1mm | |
Depth | 6.5mm | |
Height | 5mm | |
Dimensions | 7.1 x 6.5 x 5mm | |
Shielded | Yes | |
Tolerance | ±20% | |
Maximum DC Resistance | 23.7mΩ | |
Series | SPM | |
Core Material | Metallic Magnetic | |
Minimum Operating Temperature | -40°C | |
Moulded | Yes | |
Inductor Construction | Wire-Wound | |
Maximum Operating Temperature | +125°C | |
Select all | ||
---|---|---|
Brand TDK | ||
Inductance 4.7 μH | ||
Maximum DC Current 7A | ||
Package/Case 6550 | ||
Length 7.1mm | ||
Depth 6.5mm | ||
Height 5mm | ||
Dimensions 7.1 x 6.5 x 5mm | ||
Shielded Yes | ||
Tolerance ±20% | ||
Maximum DC Resistance 23.7mΩ | ||
Series SPM | ||
Core Material Metallic Magnetic | ||
Minimum Operating Temperature -40°C | ||
Moulded Yes | ||
Inductor Construction Wire-Wound | ||
Maximum Operating Temperature +125°C | ||
SPM Series Magnetic Shield Type Wound Inductors
SPM Series Magnetic Shield Type Wound Inductors for power circuits are low profile products. Those wirewound surface mount inductors offer low inductance variance in high-temperature environments with good DC superimposition characteristics.
Features
Magnetic shield type inductor for power circuits using a metallic magnetic material.
Large current, low Rdc and compact.
Low inductance variance in high-temperature environments.
Structure with an integrated molded coil
Applications
Power supply around the CPU, HDDs, servers, VRMs, compact power supply modules
