Vishay, IHLP, EK Shielded Wire-wound SMD Inductor with a Metal Composite Core, 3.3 μH ±20% Shielded 9.2A Idc
- RS Stock No.:
- 565-213
- Mfr. Part No.:
- IHLP3232DZEK3R3M01
- Brand:
- Vishay
Subtotal (1 reel of 1250 units)*
£601.25
(exc. VAT)
£721.25
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
1250 + | £0.481 | £601.25 |
*price indicative
- RS Stock No.:
- 565-213
- Mfr. Part No.:
- IHLP3232DZEK3R3M01
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Inductance | 3.3 μH | |
Maximum DC Current | 9.2A | |
Package/Case | EK | |
Length | 0.34in | |
Depth | 0.16in | |
Shielded | Yes | |
Tolerance | ±20% | |
Series | IHLP | |
Core Material | Metal Composite | |
Inductor Construction | Shielded | |
Select all | ||
---|---|---|
Brand Vishay | ||
Inductance 3.3 μH | ||
Maximum DC Current 9.2A | ||
Package/Case EK | ||
Length 0.34in | ||
Depth 0.16in | ||
Shielded Yes | ||
Tolerance ±20% | ||
Series IHLP | ||
Core Material Metal Composite | ||
Inductor Construction Shielded | ||
Xtra Guard 1 - Foil Shield
The Alpha Wire Xtra Guard 1 - Foil Shield is a high performance industrial cable. The foil shield provides moderate EMI protection, especially at lower frequencies. A tinned copper drain wire makes grounding the cable easy.
Features and Benefits
High performace cable
Good water and chemical resistance
60°C Oil (Oil Res I)
Fast, easy stripping of insulation and jacket
Premium grade PVC insulation and jacket
UV resistant, UL SUN RES
Applications
High technology application in controlled environments
Medical electronics
Point of sale equipment
Computer peripherals
Industrial process control
Note
Xtra Guard™ is a registered trademark of Alpha Wire
Standards
IEC Flame ratings: IEC 60332-1 & -2, UL SUN RES
Approvals
UL, CSA
The Vishay Power Inductor with shielded construction ensures minimal EMI and reliable performance in compact designs. It offers excellent DC/DC energy storage in the 1 MHz to 2 MHz range and operates at temperatures up to 125 °C. Features the lowest DCR per μH in its package size, providing high efficiency for power conversion applications.
Handles high transient current spikes without saturation
Ultra low buzz noise, due to composite construction
RoHS Compliant
Halogen free
Ultra low buzz noise, due to composite construction
RoHS Compliant
Halogen free
