Vishay, IHLP, EK Shielded Wirewound Surface Mount Inductor with a Metal Composite Core, 47 μH ±20 % 8.7 A Idc
- RS Stock No.:
- 565-128
- Mfr. Part No.:
- IHLP6767GZEK470M11
- Brand:
- Vishay
Bulk discount available
Subtotal (1 tape of 2 units)*
£6.44
(exc. VAT)
£7.72
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 248 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 2 - 18 | £3.22 | £6.44 |
| 20 - 98 | £2.61 | £5.22 |
| 100 - 198 | £1.995 | £3.99 |
| 200 + | £1.77 | £3.54 |
*price indicative
- RS Stock No.:
- 565-128
- Mfr. Part No.:
- IHLP6767GZEK470M11
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Wirewound Surface Mount Inductor | |
| Inductance | 47 μH | |
| Maximum DC Current | 8.7A | |
| Package/Case | EK | |
| Length | 0.68in | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Pin Count | 2 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 125°C | |
| Inductance Tolerance | ±20 % | |
| Series | IHLP | |
| Core Material | Metal Composite | |
| Standards/Approvals | RoHS | |
| Diameter | 0.28 in | |
| Depth | 0.28in | |
| Height | 7mm | |
| Termination Style | EK | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Wirewound Surface Mount Inductor | ||
Inductance 47 μH | ||
Maximum DC Current 8.7A | ||
Package/Case EK | ||
Length 0.68in | ||
Automotive Standard No | ||
Shielding Yes | ||
Pin Count 2 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
Inductance Tolerance ±20 % | ||
Series IHLP | ||
Core Material Metal Composite | ||
Standards/Approvals RoHS | ||
Diameter 0.28 in | ||
Depth 0.28in | ||
Height 7mm | ||
Termination Style EK | ||
Inductor Construction Shielded | ||
The Vishay Power Inductor with shielded construction ensures minimal electromagnetic interference and consistent performance. Designed to handle high transient current spikes without saturation, it delivers reliable energy storage in dynamic power conditions. Ideal for compact, high-efficiency DC/DC converter applications.
Ultra low buzz noise, due to composite construction
RoHS Compliant
Halogen free
