Vishay, IHLP, EK Shielded Wirewound Surface Mount Inductor with a Metal Composite Core, 4.7 μH ±20 % 5.5 A Idc
- RS Stock No.:
- 565-025
- Mfr. Part No.:
- IHLP2525CZEK4R7MA1
- Brand:
- Vishay
Subtotal (1 reel of 2500 units)*
£1,070.00
(exc. VAT)
£1,285.00
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Reel* |
|---|---|---|
| 2500 + | £0.428 | £1,070.00 |
*price indicative
- RS Stock No.:
- 565-025
- Mfr. Part No.:
- IHLP2525CZEK4R7MA1
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Wirewound Surface Mount Inductor | |
| Inductance | 4.7 μH | |
| Maximum DC Current | 5.5A | |
| Package/Case | EK | |
| Packaging | Tape & Reel | |
| Length | 0.27in | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 40mΩ | |
| Pin Count | 2 | |
| Maximum Operating Temperature | 125°C | |
| Series | IHLP | |
| Inductance Tolerance | ±20 % | |
| Core Material | Metal Composite | |
| Diameter | 0.12 in | |
| Termination Style | EK | |
| Standards/Approvals | RoHS | |
| Depth | 0.12in | |
| Height | 3mm | |
| Maximum Self Resonant Frequency | 25MHz | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Wirewound Surface Mount Inductor | ||
Inductance 4.7 μH | ||
Maximum DC Current 5.5A | ||
Package/Case EK | ||
Packaging Tape & Reel | ||
Length 0.27in | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 40mΩ | ||
Pin Count 2 | ||
Maximum Operating Temperature 125°C | ||
Series IHLP | ||
Inductance Tolerance ±20 % | ||
Core Material Metal Composite | ||
Diameter 0.12 in | ||
Termination Style EK | ||
Standards/Approvals RoHS | ||
Depth 0.12in | ||
Height 3mm | ||
Maximum Self Resonant Frequency 25MHz | ||
Inductor Construction Shielded | ||
The Vishay Automotive inductors feature a low 3.0 mm height, making them Ideal for Compact automotive designs. With shielded construction, they provide excellent DC/DC energy storage up to 5 MHz. They offer the lowest DCR per μH in their package size and can handle high transient current spikes without hard saturation, ensuring robust and efficient performance.
Ultra low buzz noise, due to composite construction
AEC Q200 qualified
RoHS Compliant
Halogen free
