Vishay, IHLP, EK Shielded Wire-wound SMD Inductor with a Metal Composite Core, 3.3 μH ±20% Shielded 7A Idc
- RS Stock No.:
- 565-020
- Mfr. Part No.:
- IHLP2525CZEK3R3M11
- Brand:
- Vishay
Subtotal (1 reel of 2500 units)*
£835.00
(exc. VAT)
£1,002.50
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 2,500 unit(s) shipping from 10 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
2500 + | £0.334 | £835.00 |
*price indicative
- RS Stock No.:
- 565-020
- Mfr. Part No.:
- IHLP2525CZEK3R3M11
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Inductance | 3.3 μH | |
Maximum DC Current | 7A | |
Package/Case | EK | |
Length | 0.27in | |
Depth | 0.12in | |
Shielded | Yes | |
Tolerance | ±20% | |
Series | IHLP | |
Core Material | Metal Composite | |
Inductor Construction | Shielded | |
Select all | ||
---|---|---|
Brand Vishay | ||
Inductance 3.3 μH | ||
Maximum DC Current 7A | ||
Package/Case EK | ||
Length 0.27in | ||
Depth 0.12in | ||
Shielded Yes | ||
Tolerance ±20% | ||
Series IHLP | ||
Core Material Metal Composite | ||
Inductor Construction Shielded | ||
FN 660 Series Two-stage General Purpose Filters
The FN 660 Series of Schaffner Two-stage general purpose filters. All models are highly reliable and excellent quality. FN 660 offer extra inductance stage for higher common mode attenuation. This series is designed to provide an economic solution for many general purpose filtering requirements. Available in 14 versions, with current ratings from 1 to 20A and with a choice of four different styles of connection. Application requirements are easily and economically matched.
Features and Benefits
Current ratings from 1 A to 20 A
High differential and common mode attenuation
Four choices of output connector
Optional medical versions (B type)
The Vishay Power Inductor with a low 3.0 mm height offers the lowest profile in its package footprint, ideal for space-constrained designs. It features shielded construction for reduced EMI and excellent energy storage for DC/DC converter applications up to 5 MHz. Suitable for filtering applications up to the self-resonant frequency.
Handles high transient current spikes without saturation
Ultra low buzz noise, due to composite construction
RoHS Compliant
Halogen free
Ultra low buzz noise, due to composite construction
RoHS Compliant
Halogen free
