Wurth Elektronik, WEPDF Shielded Surface Mount Inductor with a Iron Alloy Core, 8.2 μH 5.05 A Idc
- RS Stock No.:
- 548-632
- Mfr. Part No.:
- 7447797820
- Brand:
- Wurth Elektronik
Bulk discount available
View bulk pricing optionsSubtotal (1 tape of 5 units)*
£11.15
(exc. VAT)
£13.40
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 500 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 20 | £2.23 | £11.15 |
| 25 + | £2.162 | £10.81 |
*price indicative
- RS Stock No.:
- 548-632
- Mfr. Part No.:
- 7447797820
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Inductance | 8.2μH | |
| Product Type | Surface Mount Inductor | |
| Maximum DC Current | 5.05A | |
| Packaging | Tape & Reel | |
| Length | 10.2mm | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -40°C | |
| Maximum DC Resistance | 28.6mΩ | |
| Maximum Operating Temperature | 150°C | |
| Series | WEPDF | |
| Standards/Approvals | RoHS, REACH, Halogen-Free | |
| Termination Style | Package | |
| Diameter | 4.5mm | |
| Core Material | Iron Alloy | |
| Height | 4.5mm | |
| Depth | 4.5mm | |
| Inductor Construction | Wirewound | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Inductance 8.2μH | ||
Product Type Surface Mount Inductor | ||
Maximum DC Current 5.05A | ||
Packaging Tape & Reel | ||
Length 10.2mm | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -40°C | ||
Maximum DC Resistance 28.6mΩ | ||
Maximum Operating Temperature 150°C | ||
Series WEPDF | ||
Standards/Approvals RoHS, REACH, Halogen-Free | ||
Termination Style Package | ||
Diameter 4.5mm | ||
Core Material Iron Alloy | ||
Height 4.5mm | ||
Depth 4.5mm | ||
Inductor Construction Wirewound | ||
- COO (Country of Origin):
- TH
The Wurth Elektronik The SMT Shielded Power Inductor with a magnetic iron alloy core is engineered to handle high-rated currents, making it ideal for demanding applications. Its robust construction ensures minimal acoustic noise and low leakage flux, enhancing overall system efficiency and reliability. Operating within a wide temperature range of –40°C to +125°C, this inductor is AEC-Q200 qualified, ensuring compliance with stringent automotive standards.
Low self losses
High saturation current
Flat wire coil for lower losses at high frequency ranges
High self resonance frequency
