Bourns, SRN5040TA, 5040 Shielded Power Inductor with a Ferrite Core, 10 μH Semi Shielded ±20 % 2.2 A Idc Q:15
- RS Stock No.:
- 466-243
- Mfr. Part No.:
- SRN5040TA-100M
- Brand:
- Bourns
Bulk discount available
Subtotal (1 bag of 2 units)*
£0.60
(exc. VAT)
£0.72
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1,500 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 - 48 | £0.30 | £0.60 |
| 50 - 198 | £0.255 | £0.51 |
| 200 - 998 | £0.19 | £0.38 |
| 1000 + | £0.155 | £0.31 |
*price indicative
- RS Stock No.:
- 466-243
- Mfr. Part No.:
- SRN5040TA-100M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Power Inductor | |
| Inductance | 10μH | |
| Maximum DC Current | 2.2A | |
| Package/Case | 5040 | |
| Packaging | 1500 pieces per 13 in Reel | |
| Length | 4.95mm | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Minimum Operating Temperature | -55°C | |
| Maximum DC Resistance | 0.56Ω | |
| Inductance Tolerance | ±20 % | |
| Series | SRN5040TA | |
| Maximum Operating Temperature | 125°C | |
| Depth | 4.95mm | |
| Diameter | 4.95mm | |
| Core Material | Ferrite | |
| Standards/Approvals | AEC-Q200, Halogen Free, RoHS | |
| Height | 4.95mm | |
| Maximum Self Resonant Frequency | 250MHz | |
| Inductor Construction | Semi Shielded | |
| Minimum Quality Factor | 15 | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Power Inductor | ||
Inductance 10μH | ||
Maximum DC Current 2.2A | ||
Package/Case 5040 | ||
Packaging 1500 pieces per 13 in Reel | ||
Length 4.95mm | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Minimum Operating Temperature -55°C | ||
Maximum DC Resistance 0.56Ω | ||
Inductance Tolerance ±20 % | ||
Series SRN5040TA | ||
Maximum Operating Temperature 125°C | ||
Depth 4.95mm | ||
Diameter 4.95mm | ||
Core Material Ferrite | ||
Standards/Approvals AEC-Q200, Halogen Free, RoHS | ||
Height 4.95mm | ||
Maximum Self Resonant Frequency 250MHz | ||
Inductor Construction Semi Shielded | ||
Minimum Quality Factor 15 | ||
- COO (Country of Origin):
- CN
The Bourns Semi-shielded power inductors feature semi-shielded construction for effective noise reduction. They are suitable for high power applications that require efficient energy transfer and minimal interference.
RoHS compliant
AEC Q200 compliant
