Bourns, SRR1280, 1280 Shielded Power Inductor with a Ferrite Core, 120 μH ±20 % 1.95 A Idc Q:16
- RS Stock No.:
- 466-167
- Mfr. Part No.:
- SRR1280-121K
- Brand:
- Bourns
Subtotal (1 bag of 2 units)*
£1.49
(exc. VAT)
£1.788
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 396 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 2 + | £0.745 | £1.49 |
*price indicative
- RS Stock No.:
- 466-167
- Mfr. Part No.:
- SRR1280-121K
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Power Inductor | |
| Inductance | 120μH | |
| Maximum DC Current | 1.95A | |
| Package/Case | 1280 | |
| Length | 12.5mm | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Minimum Operating Temperature | -40°C | |
| Maximum DC Resistance | 1700.0mΩ | |
| Maximum Operating Temperature | 125°C | |
| Inductance Tolerance | ±20 % | |
| Series | SRR1280 | |
| Standards/Approvals | RoHS | |
| Core Material | Ferrite | |
| Height | 12.5mm | |
| Diameter | 12.5mm | |
| Depth | 12.5mm | |
| Maximum Self Resonant Frequency | 7.96MHz | |
| Minimum Quality Factor | 16 | |
| Inductor Construction | Shielded | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Power Inductor | ||
Inductance 120μH | ||
Maximum DC Current 1.95A | ||
Package/Case 1280 | ||
Length 12.5mm | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Minimum Operating Temperature -40°C | ||
Maximum DC Resistance 1700.0mΩ | ||
Maximum Operating Temperature 125°C | ||
Inductance Tolerance ±20 % | ||
Series SRR1280 | ||
Standards/Approvals RoHS | ||
Core Material Ferrite | ||
Height 12.5mm | ||
Diameter 12.5mm | ||
Depth 12.5mm | ||
Maximum Self Resonant Frequency 7.96MHz | ||
Minimum Quality Factor 16 | ||
Inductor Construction Shielded | ||
- COO (Country of Origin):
- CN
The Bourns Shielded SMD power inductors, available in E12 values. These inductors are designed for high performance applications requiring efficient power management in compact designs.
RoHS compliant
