Wurth, WE-HCI, 1365 Shielded Wire-wound SMD Inductor with a Polystyrene Core, 6 μH ±20% Flat Wire Winding 12A Idc
- RS Stock No.:
- 296-235
- Mfr. Part No.:
- 7443551600
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 tape of 2 units)*
£5.84
(exc. VAT)
£7.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
---|---|---|
2 - 18 | £2.92 | £5.84 |
20 - 198 | £2.63 | £5.26 |
200 - 998 | £2.425 | £4.85 |
1000 - 1998 | £2.25 | £4.50 |
2000 + | £2.015 | £4.03 |
*price indicative
- RS Stock No.:
- 296-235
- Mfr. Part No.:
- 7443551600
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Inductance | 6 μH | |
Maximum DC Current | 12A | |
Package/Case | 1365 | |
Length | 13mm | |
Automotive Standard | AEC-Q200 | |
Depth | 6.2mm | |
Shielded | Yes | |
Tolerance | ±20% | |
Series | WE-HCI | |
Core Material | Polystyrene | |
Inductor Construction | Flat Wire Winding | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Inductance 6 μH | ||
Maximum DC Current 12A | ||
Package/Case 1365 | ||
Length 13mm | ||
Automotive Standard AEC-Q200 | ||
Depth 6.2mm | ||
Shielded Yes | ||
Tolerance ±20% | ||
Series WE-HCI | ||
Core Material Polystyrene | ||
Inductor Construction Flat Wire Winding | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik SMT Flat Wire High Current Inductor AECQ 200 qualified magnetically shielded coil for low losses at high frequency features low stray field. It has an operating temperature range from –40°C to +125°C, +150°C, and +155°C, and is recommended for reflow soldering.
