Renesas Electronics SRAM, R1WV6416RBG-7SI#B0- 64Mbit
- RS Stock No.:
- 767-5963
- Mfr. Part No.:
- R1WV6416RBG-7SI#B0
- Brand:
- Renesas Electronics
Discontinued
- RS Stock No.:
- 767-5963
- Mfr. Part No.:
- R1WV6416RBG-7SI#B0
- Brand:
- Renesas Electronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Renesas Electronics | |
| Memory Size | 64Mbit | |
| Organisation | 4M x 16 bit | |
| Number of Words | 4M | |
| Number of Bits per Word | 16bit | |
| Maximum Random Access Time | 70ns | |
| Low Power | Yes | |
| Timing Type | Asynchronous | |
| Mounting Type | Surface Mount | |
| Package Type | FBGA | |
| Pin Count | 48 | |
| Dimensions | 8.5 x 11 x 0.8mm | |
| Maximum Operating Supply Voltage | 3.6 V | |
| Height | 0.8mm | |
| Minimum Operating Supply Voltage | 2.7 V | |
| Minimum Operating Temperature | -40 °C | |
| Width | 11mm | |
| Length | 8.5mm | |
| Maximum Operating Temperature | +85 °C | |
| Select all | ||
|---|---|---|
Brand Renesas Electronics | ||
Memory Size 64Mbit | ||
Organisation 4M x 16 bit | ||
Number of Words 4M | ||
Number of Bits per Word 16bit | ||
Maximum Random Access Time 70ns | ||
Low Power Yes | ||
Timing Type Asynchronous | ||
Mounting Type Surface Mount | ||
Package Type FBGA | ||
Pin Count 48 | ||
Dimensions 8.5 x 11 x 0.8mm | ||
Maximum Operating Supply Voltage 3.6 V | ||
Height 0.8mm | ||
Minimum Operating Supply Voltage 2.7 V | ||
Minimum Operating Temperature -40 °C | ||
Width 11mm | ||
Length 8.5mm | ||
Maximum Operating Temperature +85 °C | ||
- COO (Country of Origin):
- JP
Low Power SRAM, R1WV Series, Renesas Electronics
The R1WV Series of advanced low voltage static RAMs is suitable for memory applications where a simple interfacing, battery operating and battery backup are the important design objectives.
Single 2.7V to 3.6V power supply
Small stand-by current
No clocks, No refresh required
All inputs and outputs are TTL compatible
Small stand-by current
No clocks, No refresh required
All inputs and outputs are TTL compatible
SRAM (Static Random Access Memory)
