RS PRO 45 Teeth Spur Gear, 0.7 Module, 6mm Bore Diam, 31.5mm Pitch Diam, 18mm Hub Diam
- RS Stock No.:
- 182-7914
- Brand:
- RS PRO
2 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 2)
£4.105
(exc. VAT)
£4.926
(inc. VAT)
| Units | Per unit | Per Pack* |
| 2 - 8 | £4.105 | £8.21 |
| 10 - 18 | £4.03 | £8.06 |
| 20 + | £3.945 | £7.89 |
| *price indicative | ||
- RS Stock No.:
- 182-7914
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
RS PRO Spur Gear
The RS PRO 45 teeth metric spur gear has a pitch diameter of 31.5mm, hub diameter of 18mm and bore diameter of 6mm. The gear has a face width of 6mm. It has a module value of 0.7.
Features and Benefits
• Standard tolerances, unless otherwise stated 0.25mm
• Moulded HOSTAFORM to DIN3962/63/67 grade 12
• Moulded HOSTAFORM to DIN3962/63/67 grade 12
Certifications
• EN certified
Specifications
Attribute | Value |
|---|---|
| Module | 0.7 |
| Number of Teeth | 45 |
| Bore Diameter | 6mm |
| Pitch Diameter | 31.5mm |
| Hub Diameter | 18mm |
| Face Width | 6mm |
