Neutrik Right Angle Cable Mount Loudspeaker Connector Socket, 4 Way, 40A, Screw Termination
- RS Stock No.:
- 426-2331
- Mfr. Part No.:
- NL4FRX
- Brand:
- Neutrik
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 426-2331
- Mfr. Part No.:
- NL4FRX
- Brand:
- Neutrik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Neutrik | |
| Gender | Female | |
| Number of Contacts | 4 | |
| Body Orientation | Right Angle | |
| Contact Material | Brass | |
| Mounting Type | Cable Mount | |
| Housing Material | PBT | |
| Contact Plating | Silver | |
| Termination Method | Screw | |
| Current Rating | 40A | |
| Voltage Rating | 250 V | |
| Maximum Operating Temperature | +80°C | |
| Minimum Operating Temperature | -30°C | |
Select all | ||
|---|---|---|
Brand Neutrik | ||
Gender Female | ||
Number of Contacts 4 | ||
Body Orientation Right Angle | ||
Contact Material Brass | ||
Mounting Type Cable Mount | ||
Housing Material PBT | ||
Contact Plating Silver | ||
Termination Method Screw | ||
Current Rating 40A | ||
Voltage Rating 250 V | ||
Maximum Operating Temperature +80°C | ||
Minimum Operating Temperature -30°C | ||
- COO (Country of Origin):
- LI
Neutrik speakON Lockable Loudspeaker Cable Plugs
Optimised for loudspeaker application, Neutrik invented speakON a high quality, reliable speaker connection in 1987. Built to perform this connection system has proved to be user friendly, reliable and simple to use.
The speakOn series of loudspeaker connectors offers an extremely precise locking system with "quick lock" technology. With three easy assembly parts and improved grip, setting up broadcasting, audio, concert or telecommunication equipment couldn't be easier. With chuck type strain relief you can be reassured that cable life is extended whilst safety requirements are also met.
The speakOn series of loudspeaker connectors offers an extremely precise locking system with "quick lock" technology. With three easy assembly parts and improved grip, setting up broadcasting, audio, concert or telecommunication equipment couldn't be easier. With chuck type strain relief you can be reassured that cable life is extended whilst safety requirements are also met.
Features and Benefits:
• 2, 4 and 8-pole connectors available
• "Quick Lock" system
• Robust and reliable speaker connectors
• Quick and easy to assemble
• Optimised design
• Improved screw-type termination
• 1.5 - 4 mm² wire size (AWG 12)
• "Quick Lock" system
• Robust and reliable speaker connectors
• Quick and easy to assemble
• Optimised design
• Improved screw-type termination
• 1.5 - 4 mm² wire size (AWG 12)
How do I wire speaker connectors?
This varies with each connector, however for the speakOn series a pozidrive #1 can be used. Theses connectors feature improved screw contacts and progressive clamping, this means the wires are pushed forward acting as a locking device to protect them further.
