RS PRO Uninsulated Male Spade Connector, PCB Receptacle, 6.35 x 0.8mm Tab Size
- RS Stock No.:
- 178-8411
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 bag of 100 units)*
£5.60
(exc. VAT)
£6.70
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1,700 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 100 - 900 | £0.056 | £5.60 |
| 1000 - 1900 | £0.051 | £5.10 |
| 2000 - 4900 | £0.046 | £4.60 |
| 5000 - 9900 | £0.043 | £4.30 |
| 10000 + | £0.039 | £3.90 |
*price indicative
- RS Stock No.:
- 178-8411
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Spade Connector Type | Receptacle | |
| Type | PCB Receptacle | |
| Gender | Male | |
| Tab Thickness | 0.8mm | |
| Tab Width | 6.35mm | |
| Tab Size | 6.35 x 0.8mm | |
| Insulation | Uninsulated | |
| Termination Method | Solder | |
| Contact Material | Brass | |
| Contact Plating | Tin | |
| Shrouded/Unshrouded | Unshrouded | |
| Overall Length | 16.5mm | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Spade Connector Type Receptacle | ||
Type PCB Receptacle | ||
Gender Male | ||
Tab Thickness 0.8mm | ||
Tab Width 6.35mm | ||
Tab Size 6.35 x 0.8mm | ||
Insulation Uninsulated | ||
Termination Method Solder | ||
Contact Material Brass | ||
Contact Plating Tin | ||
Shrouded/Unshrouded Unshrouded | ||
Overall Length 16.5mm | ||
- COO (Country of Origin):
- TW
RS PRO Uninsulated Male Terminals, Tin Plated, 0.8x6.35
From our trusted and reliable own brand RS PRO, these uninsulated male terminals feature a brass construction with tin plating, offering a reliable wire connection with great corrosion resistance. These quick disconnect male terminals feature a terminal thickness of 0.45mm and are ideal for applications that require simple wire installation solutions for two wires to be connected and disconnected quickly.
Features and Benefits
- Brass construction offering a durable terminal and corrosion resistance
- Tin plated ensuring great conductivity
- Ideal for quick connection and disconnection of two wires
Applications
These male terminals are often used in areas such as:
- Automotive
- Industrial
- Consumer
Why RS PRO?
RS PRO is our own brand range and brings you a wide selection of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards theyre only given the RS PRO seal of approval if were confident of their exceptional quality, which means you can be confident too.
