RS PRO Blue Insulated Male Spade Connector, Tab, 0.8 x 6.35mm Tab Size, 1.5mm² to 2.5mm²
- RS Stock No.:
- 178-8368
- Brand:
- RS PRO
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 178-8368
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Type | Tab | |
| Gender | Male | |
| Minimum Wire Size mm² | 1.5mm² | |
| Maximum Wire Size mm² | 2.5mm² | |
| Tab Width | 6.35mm | |
| Tab Thickness | 0.8mm | |
| Tab Size | 0.8 x 6.35mm | |
| Insulation | Insulated | |
| Maximum Wire Size AWG | 14AWG | |
| Minimum Wire Size AWG | 16AWG | |
| Termination Method | Crimp | |
| Colour | Blue | |
| Contact Material | Brass | |
| Wire Size | 1.5 → 2.5 mm², 16 → 14 AWG | |
| Insulation Material | Nylon | |
| Overall Length | 24.6mm | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Type Tab | ||
Gender Male | ||
Minimum Wire Size mm² 1.5mm² | ||
Maximum Wire Size mm² 2.5mm² | ||
Tab Width 6.35mm | ||
Tab Thickness 0.8mm | ||
Tab Size 0.8 x 6.35mm | ||
Insulation Insulated | ||
Maximum Wire Size AWG 14AWG | ||
Minimum Wire Size AWG 16AWG | ||
Termination Method Crimp | ||
Colour Blue | ||
Contact Material Brass | ||
Wire Size 1.5 → 2.5 mm², 16 → 14 AWG | ||
Insulation Material Nylon | ||
Overall Length 24.6mm | ||
- COO (Country of Origin):
- TW
RS PRO NYLON-FULLY INSULATED MALE DISCONNECTORS
