Celduc SO4 Series Solid State Relay, 95 A Load, Panel Mount, 480 V ac Load, 10 V dc Control
- RS Stock No.:
- 917-4769
- Mfr. Part No.:
- SO468020
- Brand:
- Celduc
Subtotal (1 unit)*
£207.21
(exc. VAT)
£248.65
(inc. VAT)
FREE delivery for orders over £50.00
- 4 unit(s) ready to ship from another location
Units | Per unit |
|---|---|
| 1 - 4 | £207.21 |
| 5 - 9 | £201.45 |
| 10 + | £196.01 |
*price indicative
- RS Stock No.:
- 917-4769
- Mfr. Part No.:
- SO468020
- Brand:
- Celduc
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 95 A | |
| Mounting Type | Panel Mount | |
| Maximum Load Voltage | 480 V ac | |
| Minimum Load Voltage | 200 V ac | |
| Maximum Control Voltage | 10 V dc | |
| Minimum Control Voltage | 0 V dc | |
| Switching Type | Analogue Control | |
| Control Voltage Range | 0 → 10 V dc | |
| Minimum Load Current | 0.1 A | |
| Range | SO4 | |
| Number of Poles | 1 | |
| Terminal Type | Spring | |
| Output Device | Thyristor | |
| Relay Type | AC | |
| Maximum Turn On Time | 20ms | |
| Series | SO4 | |
| Load Voltage Range | 200 → 480V ac | |
| Dimensions | 45 x 58.2 x 27mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +90°C | |
| Depth | 58.2mm | |
| Height | 27mm | |
| Special Features | Over-Voltage Protection by Varistor, IP20 Protection by Flaps on Terminals | |
| Standards Met | CE Certified, cULus Recognized | |
| Off State Leakage Current | 2 mA | |
| Length | 45mm | |
| Operating Temperature Range | -40 → +90°C | |
Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 95 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 480 V ac | ||
Minimum Load Voltage 200 V ac | ||
Maximum Control Voltage 10 V dc | ||
Minimum Control Voltage 0 V dc | ||
Switching Type Analogue Control | ||
Control Voltage Range 0 → 10 V dc | ||
Minimum Load Current 0.1 A | ||
Range SO4 | ||
Number of Poles 1 | ||
Terminal Type Spring | ||
Output Device Thyristor | ||
Relay Type AC | ||
Maximum Turn On Time 20ms | ||
Series SO4 | ||
Load Voltage Range 200 → 480V ac | ||
Dimensions 45 x 58.2 x 27mm | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +90°C | ||
Depth 58.2mm | ||
Height 27mm | ||
Special Features Over-Voltage Protection by Varistor, IP20 Protection by Flaps on Terminals | ||
Standards Met CE Certified, cULus Recognized | ||
Off State Leakage Current 2 mA | ||
Length 45mm | ||
Operating Temperature Range -40 → +90°C | ||
- COO (Country of Origin):
- FR
Regulator solid state relays
Integrated varistors to protect against overvoltage.
Two spring-technology pull-out connectors.
Protection index: IP20.
