Celduc SK Series Solid State Relay, 5 A Load, PCB Mount, 600 V ac Load, 10 V dc Control
- RS Stock No.:
- 917-4731
- Mfr. Part No.:
- SKB10440
- Brand:
- Celduc
- RS Stock No.:
- 917-4731
- Mfr. Part No.:
- SKB10440
- Brand:
- Celduc
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 5 A | |
| Mounting Type | PCB Mount | |
| Maximum Load Voltage | 600 V ac | |
| Minimum Load Voltage | 24 V ac | |
| Maximum Control Voltage | 10 V dc | |
| Minimum Control Voltage | 3.7 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 3.7 → 10 V dc | |
| Minimum Load Current | 1 mA | |
| Range | SK | |
| Number of Poles | 1 | |
| Terminal Type | PCB Pin | |
| Output Device | Triac | |
| Package Style | SIP4 | |
| Relay Type | AC | |
| Series | SK | |
| Maximum Turn On Time | 10ms | |
| Load Voltage Range | 24 → 600V ac | |
| Dimensions | 43.2 x 10.2 x 25.4mm | |
| Depth | 10.2mm | |
| Height | 25.4mm | |
| Standards Met | CE, VDE, EAC, cURus | |
| Special Features | Zero Cross Solid State Relay for Printed Circuit Board designed for Resistive Loads, Lamps or Inductive Loads with External VDR, Very low leakage current | |
| Operating Temperature Range | -40 → +100°C | |
| Off State Leakage Current | 0.1 mA | |
| Minimum Operating Temperature | -40°C | |
| Length | 43.2mm | |
| Maximum Operating Temperature | +100°C | |
| Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 5 A | ||
Mounting Type PCB Mount | ||
Maximum Load Voltage 600 V ac | ||
Minimum Load Voltage 24 V ac | ||
Maximum Control Voltage 10 V dc | ||
Minimum Control Voltage 3.7 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 3.7 → 10 V dc | ||
Minimum Load Current 1 mA | ||
Range SK | ||
Number of Poles 1 | ||
Terminal Type PCB Pin | ||
Output Device Triac | ||
Package Style SIP4 | ||
Relay Type AC | ||
Series SK | ||
Maximum Turn On Time 10ms | ||
Load Voltage Range 24 → 600V ac | ||
Dimensions 43.2 x 10.2 x 25.4mm | ||
Depth 10.2mm | ||
Height 25.4mm | ||
Standards Met CE, VDE, EAC, cURus | ||
Special Features Zero Cross Solid State Relay for Printed Circuit Board designed for Resistive Loads, Lamps or Inductive Loads with External VDR, Very low leakage current | ||
Operating Temperature Range -40 → +100°C | ||
Off State Leakage Current 0.1 mA | ||
Minimum Operating Temperature -40°C | ||
Length 43.2mm | ||
Maximum Operating Temperature +100°C | ||
- COO (Country of Origin):
- FR
