Toshiba Solid State Relay, Surface Mount, 80 V Control
- RS Stock No.:
- 885-1455
- Mfr. Part No.:
- TLP3556(F)
- Brand:
- Toshiba
Stock information currently inaccessible
- RS Stock No.:
- 885-1455
- Mfr. Part No.:
- TLP3556(F)
- Brand:
- Toshiba
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Toshiba | |
| Mounting Type | Surface Mount | |
| Maximum Control Voltage | 80 V | |
| Switching Type | AC/DC | |
| Control Voltage Range | Maximum of 80 V | |
| Number of Poles | 1 | |
| Contact Configuration | SPST | |
| Terminal Type | PCB Pin | |
| Output Device | MOSFET | |
| Relay Type | PhotoMOSFET | |
| Package Style | DIP | |
| Maximum Turn On Time | 5ms | |
| Dimensions | 4.58 x 6.4 x 3.65mm | |
| Depth | 6.4mm | |
| Maximum Operating Temperature | +85°C | |
| Off State Leakage Current | 1 μA | |
| Height | 3.7mm | |
| Special Features | High Current Photorelays | |
| Operating Temperature Range | -40 → +85°C | |
| Length | 4.6mm | |
| Minimum Operating Temperature | -40°C | |
| Capacitance | 200pF | |
| Select all | ||
|---|---|---|
Brand Toshiba | ||
Mounting Type Surface Mount | ||
Maximum Control Voltage 80 V | ||
Switching Type AC/DC | ||
Control Voltage Range Maximum of 80 V | ||
Number of Poles 1 | ||
Contact Configuration SPST | ||
Terminal Type PCB Pin | ||
Output Device MOSFET | ||
Relay Type PhotoMOSFET | ||
Package Style DIP | ||
Maximum Turn On Time 5ms | ||
Dimensions 4.58 x 6.4 x 3.65mm | ||
Depth 6.4mm | ||
Maximum Operating Temperature +85°C | ||
Off State Leakage Current 1 μA | ||
Height 3.7mm | ||
Special Features High Current Photorelays | ||
Operating Temperature Range -40 → +85°C | ||
Length 4.6mm | ||
Minimum Operating Temperature -40°C | ||
Capacitance 200pF | ||
- COO (Country of Origin):
- TH
