Gefran GQ Series Solid State Relay, 50 A Load, Surface Mount, 230 V ac Load, 260V ac/dc Control
- RS Stock No.:
- 798-4188
- Mfr. Part No.:
- GQ-50-24-A-1-1 (230V/50A)
- Brand:
- Gefran
2 In stock - FREE next working day delivery available
Added
Price Each
£69.54
(exc. VAT)
£83.45
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £69.54 |
| 5 - 9 | £66.08 |
| 10 - 24 | £62.60 |
| 25 - 49 | £59.13 |
| 50 + | £55.62 |
- RS Stock No.:
- 798-4188
- Mfr. Part No.:
- GQ-50-24-A-1-1 (230V/50A)
- Brand:
- Gefran
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
Gefran Integral Heatsinks with DIN-Rail Mounting
Heatsinks
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 50 A |
| Mounting Type | Surface Mount |
| Maximum Load Voltage | 230 V ac |
| Minimum Load Voltage | 24 V ac |
| Minimum Control Voltage | 20V ac/dc |
| Maximum Control Voltage | 260V ac/dc |
| Switching Type | Zero Cross |
| Control Voltage Range | 20 → 260 V ac/dc |
| Terminal Type | Screw |
| Output Device | SCR |
| Relay Type | Single Phase |
| Package Style | Module |
| Maximum Turn On Time | 1/2 cycle + 1 ms |
| Load Voltage Range | 24 → 230V ac |
| Series | GQ |
| Dimensions | 45 x 30.5 x 58mm |
| Maximum Operating Temperature | +80°C |
| Operating Temperature Range | -25 → +80°C |
| Minimum Operating Temperature | -25°C |
| Height | 58mm |
| Length | 45mm |
| Special Features | Red LED Drive Active Signal, Has An Optional Internal MOV |
| Depth | 30.5mm |
