Gefran GQ Series Solid State Relay, 15 A Load, Surface Mount, 230 V ac Load
- RS Stock No.:
- 225-8922
- Mfr. Part No.:
- GQ-15-24-D-1-4
- Brand:
- Gefran
Subtotal (1 unit)*
£39.46
(exc. VAT)
£47.35
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 07 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £39.46 |
*price indicative
- RS Stock No.:
- 225-8922
- Mfr. Part No.:
- GQ-15-24-D-1-4
- Brand:
- Gefran
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Gefran | |
Maximum Load Current | 15 A | |
Mounting Type | Surface Mount | |
Maximum Load Voltage | 230 V ac | |
Minimum Load Voltage | 24 V ac | |
Switching Type | Zero Cross | |
Range | GQ | |
Minimum Load Current | 500 mA | |
Output Device | Thyristor | |
Series | GQ | |
Select all | ||
---|---|---|
Brand Gefran | ||
Maximum Load Current 15 A | ||
Mounting Type Surface Mount | ||
Maximum Load Voltage 230 V ac | ||
Minimum Load Voltage 24 V ac | ||
Switching Type Zero Cross | ||
Range GQ | ||
Minimum Load Current 500 mA | ||
Output Device Thyristor | ||
Series GQ | ||
- COO (Country of Origin):
- IT
The Gefran Zero crossing relay with antiparallel thyristor output is the most used solid state relay in industrial applications. In fact, it can be used for resistive, inductive and capacity loads. "Zero crossing relay is energised when voltage meets the zero point and disenergised when current meets the zero point, depending on the signal control on the input circuit. This relay has been designed to stand high-value transitory applications . When the relay has to stand high currents for a long period, it is necessary to grant a proper dissipation and an adequate electrical connection between relay terminals and the load. Fuses, thermostats and fans are available as fittings. Use the relay with an opportune heatsink.
Alternating current solid state relay
Zero crossing switching
15 Arms nominal current
Non-repetitive voltage up to 1600Vp
Isolation ((input-output) 4000Vrms
Green LED drive active signal
Zero crossing switching
15 Arms nominal current
Non-repetitive voltage up to 1600Vp
Isolation ((input-output) 4000Vrms
Green LED drive active signal
