i-Autoc Solid State Relay, 50 A Load, Panel Mount, 280 V ac Load, 15 V dc Control
- RS Stock No.:
- 102-5568
- Mfr. Part No.:
- KSID240LD50
- Brand:
- i-Autoc
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 102-5568
- Mfr. Part No.:
- KSID240LD50
- Brand:
- i-Autoc
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | i-Autoc | |
| Maximum Load Current | 50 A | |
| Mounting Type | Panel Mount | |
| Maximum Load Voltage | 280 V ac | |
| Minimum Load Voltage | 48 V ac | |
| Minimum Control Voltage | 4 V dc | |
| Maximum Control Voltage | 15 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 4 → 15 V dc | |
| Terminal Type | Quick Connect | |
| Output Device | SCR | |
| Maximum Turn On Time | 1 (+1/2 cycle) ms | |
| Load Voltage Range | 48 → 280V ac | |
| Dimensions | 58.4 x 45.7 x 21.5mm | |
| Depth | 45.7mm | |
| Standards Met | CE | |
| Length | 58.4mm | |
| Special Features | SCR Output | |
| Operating Temperature Range | -40 → +80°C | |
| Off State Leakage Current | 5 mA | |
| Height | 21.5mm | |
| Select all | ||
|---|---|---|
Brand i-Autoc | ||
Maximum Load Current 50 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 280 V ac | ||
Minimum Load Voltage 48 V ac | ||
Minimum Control Voltage 4 V dc | ||
Maximum Control Voltage 15 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 4 → 15 V dc | ||
Terminal Type Quick Connect | ||
Output Device SCR | ||
Maximum Turn On Time 1 (+1/2 cycle) ms | ||
Load Voltage Range 48 → 280V ac | ||
Dimensions 58.4 x 45.7 x 21.5mm | ||
Depth 45.7mm | ||
Standards Met CE | ||
Length 58.4mm | ||
Special Features SCR Output | ||
Operating Temperature Range -40 → +80°C | ||
Off State Leakage Current 5 mA | ||
Height 21.5mm | ||
- COO (Country of Origin):
- CN
KSID Series 2 Channel SSR
I-Autoc KSID series two channel AC output solid state relay. KSID relays have various control voltage options with load currents at 25A and 50A available. The relays can be used for resistive, inductive or capacitive loads.
AC output
Zero crossing or Random-on
SCR output
LED indication
Opto-isolation
IP20 safety cover protection
RoHS compliant
Zero crossing or Random-on
SCR output
LED indication
Opto-isolation
IP20 safety cover protection
RoHS compliant
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
