i-Autoc Solid State Relay, 40 A Load, Panel Mount, 480 V ac Load, 10 V dc Control
- RS Stock No.:
- 102-5564
- Mfr. Part No.:
- KRA480H40R
- Brand:
- i-Autoc
Available to back order for despatch 09/10/2024
Price Each
£167.82
(exc. VAT)
£201.38
(inc. VAT)
Units | Per unit |
---|---|
1 + | £167.82 |
- RS Stock No.:
- 102-5564
- Mfr. Part No.:
- KRA480H40R
- Brand:
- i-Autoc
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
KRA Series Single Phase SSR
I-Autoc KRA series single phase AC output solid state relay. KRA relays have a variety of control voltage options with load currents at 25A, 40A, 60A, 80A available. Featuring load open and SCR fault detection and output error signal that makes the KRA series suitable for a wide variety of industrial applications.
AC output
SCR output for heavy industrial loads
Phase angle control output
LED indication
Load open detect and output error signal
SCR fault detect and output error signal
SCR output for heavy industrial loads
Phase angle control output
LED indication
Load open detect and output error signal
SCR fault detect and output error signal
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
Specifications
Attribute | Value |
---|---|
Maximum Load Current | 40 A |
Mounting Type | Panel Mount |
Maximum Load Voltage | 480 V ac |
Minimum Load Voltage | 0 V ac |
Minimum Control Voltage | 0 V dc |
Maximum Control Voltage | 10 V dc |
Switching Type | AC |
Control Voltage Range | 0 → 10 V dc |
Terminal Type | Screw |
Output Device | SCR |
Load Voltage Range | 0 → 480V ac |
Dimensions | 80 x 50 x 36.6mm |
Height | 36.6mm |
Operating Temperature Range | -30 → +80°C |
Length | 80mm |
Off State Leakage Current | 5 mA |
Special Features | LED Indication, Load Open Detect & Output Error Signal, SCR Fault Detect & Output Error Signal, SCR Output |
Depth | 50mm |
Standards Met | CE |
