Sensata / Crydom Solid State Relay, 25 A Load, Panel Mount, 280 V Load, 15 V Control
- RS Stock No.:
- 480-605
- Mfr. Part No.:
- 84140800
- Brand:
- Sensata / Crydom
Discontinued product
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 480-605
- Mfr. Part No.:
- 84140800
- Brand:
- Sensata / Crydom
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
280V Dual AC Output Relays
Dual AC output relays
Dual input channels for independent output operation
Direct bond copper substrate
Back-to-back SCR output for heavy industrial loads
Locking connector
4000 Vac optical isolation
No external transient protection required (internal TVS)
CE Compliant
Dual input channels for independent output operation
Direct bond copper substrate
Back-to-back SCR output for heavy industrial loads
Locking connector
4000 Vac optical isolation
No external transient protection required (internal TVS)
CE Compliant
Note
Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet
Approvals
UL/cUL Recognized
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 280 V |
| Maximum Control Voltage | 15 V |
| Switching Type | Zero Cross |
| Control Voltage Range | 4 → 15 V dc |
| Minimum Load Current | 100 mA |
| Output Device | SCR |
| Load Voltage Range | 24 → 280V ac |
| Operating Temperature Range | -40 → +80°C |
| Maximum Operating Temperature | +80°C |
| Height | 22.5mm |
| Length | 57.2mm |
| Minimum Operating Temperature | -40°C |
